Comprehensive guide to shoulder arthroscopy portal placement, positioning, technique, indications, complications and exam points for Orthopaedic FRACS examination
Reviewed by OrthoVellum Editorial Team
Orthopaedic clinicians and medical editors • Published by OrthoVellum Medical Education Team
Portal-Based Technique | Beach Chair vs Lateral | Minimally Invasive
Always establish posterior portal FIRST. This is the viewing portal. Locate the soft spot: 2cm medial and 2cm inferior to posterolateral acromion. All subsequent portals are created under direct arthroscopic vision.
The axillary nerve runs 5-7mm inferior to the glenoid rim as it exits the quadrangular space. It is at highest risk during anterior-inferior capsular release, inferior portal placement, and subscapularis takedown. Protect by staying superior to 5 o'clock position on right shoulder (7 o'clock on left).
The rotator interval between subscapularis and supraspinatus is the safe gateway for the anterior portal. Enter lateral to coracoid, aiming for the biceps tendon. Avoid going too inferior (axillary nerve) or too superior (cuff injury).
Beach chair vs lateral decubitus - know both. Beach chair: easier conversion to open, familiar anatomy, lower traction risk. Lateral: better posterior visualization, gravity assists with distraction, preferred by many arthroscopists for labral work.
Shoulder arthroscopy is a portal-based minimally invasive approach requiring precise anatomic knowledge. The posterior portal is established first using the "soft spot" (2cm medial, 2cm inferior to posterolateral acromion)—this is the primary viewing portal. The anterior portal is created under direct arthroscopic vision through the rotator interval (between subscapularis and supraspinatus), entering lateral to the coracoid. The axillary nerve is the structure at highest risk, running 5-7mm inferior to the glenoid rim—stay superior to the 5 o'clock position (right shoulder) or 7 o'clock (left shoulder). Beach chair positioning allows easier conversion to open surgery, while lateral decubitus provides better posterior visualization and is preferred for labral work.
Memory Hook:PORTALS guides you through safe shoulder arthroscopy portal creation
Memory Hook:BEACHES reminds you of beach chair positioning advantages and risks
Memory Hook:Remember the DANGER zones to avoid complications in shoulder arthroscopy
Shoulder arthroscopy is a minimally invasive technique providing diagnostic and therapeutic access to the glenohumeral joint, subacromial space, and acromioclavicular joint. First pioneered in the 1970s, it has become the gold standard for many shoulder pathologies.
Primary indications:
Rotator Cuff Pathology
Shoulder Instability
Biceps Pathology
Acromioclavicular Joint
Adhesive Capsulitis
Loose Bodies and Synovial Disease
Diagnostic
Advantages Over Open Surgery
Arthroscopic advantages: (1) Minimally invasive with better cosmesis, (2) Superior visualization of posterior and superior structures, (3) Ability to address multiple pathologies in same setting, (4) Faster rehabilitation for many procedures, (5) Lower infection rates. Disadvantages: Steep learning curve, requires specialized equipment, longer operative time initially, risk of fluid extravasation.
Contraindications:
Surface anatomy landmarks:
| Landmark | Location | Clinical Use |
|---|---|---|
| Posterolateral acromion | Posterior corner of acromion (bony prominence) | Reference point for posterior portal (2cm medial, 2cm inferior from this point) |
| Posterior soft spot | 2cm medial and 2cm inferior to posterolateral acromion | Palpable depression - ideal entry point for posterior viewing portal |
| Coracoid process | 2-3cm inferior to clavicle, anterior shoulder | Medial landmark for anterior portal - stay lateral to avoid neurovascular bundle |
| AC joint | Junction of distal clavicle and acromion (palpable step-off) | Landmark for AC joint procedures and superior portals |
| Clavicle | Palpable along entire length | Superior boundary, orientation landmark |
Intra-articular anatomy (systematic arthroscopic examination):
Structures at risk:
| Portal | Structure at Risk | Distance/Location | Injury Prevention |
|---|---|---|---|
| Posterior | Suprascapular nerve | Posterior to glenoid neck (spinoglenoid notch) | Avoid aggressive posterior capsular work medial to glenoid |
| Anterior | Axillary nerve | 5-7mm inferior to glenoid rim anteriorly | Stay superior to 5 o'clock (right) or 7 o'clock (left) during capsular work |
| Anterior | Musculocutaneous nerve | 3-8cm distal to coracoid in coracobrachialis | Stay lateral to coracoid, enter through rotator interval |
| Anterior | Cephalic vein | Anterior shoulder superficial to deltopectoral groove | Typically not at risk with standard anterior portal but vulnerable if too medial |
| Lateral (Neviaser) | Suprascapular nerve | Posterior scapula at spinoglenoid notch | Avoid excessive medial dissection when creating portal |
The axillary nerve is the structure at highest risk during shoulder arthroscopy. It exits the quadrangular space posteriorly and wraps around the surgical neck of the humerus, running 5-7mm inferior to the glenoid rim at the anteroinferior capsule. During anterior-inferior capsular release (for instability), Bankart repair, and subscapularis procedures, protect this nerve by staying superior to the 5 o'clock position on the right shoulder (or 7 o'clock on the left shoulder).
Rotator interval anatomy:
The rotator interval is the triangular space bordered by:
This is the safe gateway for the anterior working portal. It contains the coracohumeral ligament and superior glenohumeral ligament. Entry through this interval allows access to the glenohumeral joint while avoiding rotator cuff injury.
Key Concept: Shoulder arthroscopy does NOT use a traditional internervous plane.
Unlike open surgical approaches that exploit intervals between muscles supplied by different nerves, arthroscopy uses small stab incisions (portals) through skin, subcutaneous tissue, muscle, and capsule directly into the joint.
Definition: A surgical plane between muscles supplied by different nerves, allowing muscle separation without denervation.
Examples: Deltopectoral approach (deltoid via axillary nerve, pectoralis major via pectoral nerves), anterior approach to hip (tensor fasciae latae via superior gluteal nerve, sartorius via femoral nerve).
Principle: Muscles are retracted, not divided, preserving their nerve supply.
No internervous plane: Portals are small stab incisions (5-10mm) that pass directly through muscle and capsule into the joint.
Muscle traversed:
Key principle: Minimize tissue trauma by using small cannulas, gentle insertion, and precise portal placement under arthroscopic visualization.
Muscles traversed by standard shoulder arthroscopy portals:
| Portal | Superficial Structures | Deep Structures | Nerve Supply to Muscle |
|---|---|---|---|
| Posterior | Skin, subcutaneous tissue, deltoid (superficial) | Infraspinatus muscle, posterior capsule | Suprascapular nerve (infraspinatus) |
| Anterior | Skin, subcutaneous tissue, deltoid | Rotator interval (between subscapularis and supraspinatus), anterior capsule | Axillary nerve (deltoid), no muscle divided deeply |
| Lateral (Neviaser) | Skin, subcutaneous tissue, deltoid | Supraspinatus muscle (directly through tendon), capsule | Axillary nerve (deltoid), suprascapular nerve (supraspinatus) |
Viva Answer - Internervous Plane Question
When asked about internervous planes in shoulder arthroscopy, state: "Shoulder arthroscopy does not use a traditional internervous plane. Portals are small stab incisions that pass through muscles directly to access the joint. The posterior portal traverses infraspinatus, the lateral portal traverses supraspinatus, and the anterior portal passes through the rotator interval between subscapularis and supraspinatus. The key principle is to minimize muscle trauma through small cannulas and precise portal placement under direct arthroscopic visualization. While we pass through muscles, we minimize denervation injury by keeping portals small and avoiding excessive tissue trauma."
Why this matters for the exam:
Traditional open approaches use internervous planes to avoid denervating muscles. Arthroscopy sacrifices this principle for the benefit of minimally invasive access. The trade-off is:
The concept of "internervous plane" in arthroscopy refers more to the anatomic safety zones (e.g., rotator interval for anterior portal) rather than true planes between differently innervated muscles.
Advantages:
Disadvantages:
Setup technique:
Patient supine on operating table with beach chair back attachment. Position patient at top edge of table to allow shoulder to hang free posteriorly. Place pillow under knees.
Elevate backrest to 30-45 degrees. Ensure patient does not slide down table - use beanbag or anti-slide mattress. Check hips and knees are flexed to prevent sliding.
Secure head in padded head holder or horseshoe headrest. Tilt head 10-15 degrees away from operative shoulder to improve surgical access. Avoid excessive rotation to prevent cerebral hypoperfusion.
Arm free-draped and mobile. Use pneumatic arm holder (Spider limb positioner) or have assistant support arm. Arm should be able to move freely for examination and positioning during procedure.
Pad all bony prominences: sacrum, elbows, heels. Ensure no pressure on peroneal nerve. Communicate with anesthesia regarding blood pressure targets (MAP greater than 70mmHg). Apply eye protection.
Maintain mean arterial pressure greater than 70mmHg throughout the procedure. Risk of watershed cerebral infarcts if hypotensive in upright position. Communicate frequently with anesthesia team. Consider invasive arterial monitoring for high-risk patients or lengthy procedures.
Arm positioning during procedure:
Beach chair positioning is preferred by most Australian surgeons for its familiar anatomy and ease of conversion to open surgery.
Position Choice - Viva Answer
When asked about positioning for shoulder arthroscopy: "Both beach chair and lateral decubitus positions are acceptable and the choice is often surgeon preference. I would use beach chair position because: (1) familiar anatomy orientation, (2) easy conversion to open if needed, (3) better for stability testing, (4) easier anesthesia access. However, I would monitor blood pressure carefully to maintain MAP greater than 70mmHg to prevent cerebral hypoperfusion. Some surgeons prefer lateral decubitus for better posterior access and joint distraction, particularly for labral repairs, but this requires traction setup and makes conversion to open more difficult."
Posterior Portal Variations:
Anterior Portal Variations:
| Variant | Prevalence | Location | Clinical Significance |
|---|---|---|---|
| Sublabral foramen | 11-15% | Superior labrum 11-1 o'clock | Normal variant - do not repair, distinguish from SLAP tear |
| Buford complex | 1.5% | Absent anterosuperior labrum | Normal variant with cord-like MGHL - not pathologic |
| Os acromiale | 1-15% | Unfused anterior acromion | May affect subacromial portal trajectory, risk of displacement with decompression |
| Glenoid hypoplasia | Variable | Shallow glenoid | Affects anchor placement angles and depth perception |
Standard Portals (Used in most procedures):
| Portal | Location | Primary Function | Structures Traversed |
|---|---|---|---|
| Posterior | 2cm medial, 2cm inferior to posterolateral acromion | Viewing portal (established first) | Deltoid, infraspinatus, posterior capsule |
| Anterior | Lateral to coracoid, through rotator interval | Working portal | Deltoid, rotator interval |
| Lateral (Neviaser) | 2-3cm lateral to lateral acromion edge | Cuff repairs, SLAP | Deltoid, supraspinatus |
| Anterosuperolateral | Between anterior and lateral portals | Biceps tenodesis, superior labrum | Deltoid, supraspinatus edge |
Procedure-Specific Portal Configuration:
| Procedure | Portals Required |
|---|---|
| Diagnostic arthroscopy | Posterior (viewing) + Anterior (probe) |
| Bankart repair | Posterior + Anterior + Anteroinferior |
| SLAP repair | Posterior + Anterior + Anterosuperolateral |
| Rotator cuff repair | Posterior + Lateral + Anterolateral |
| Subacromial decompression | Posterior subacromial + Lateral subacromial |
History Assessment:
Physical Examination:
Medical Optimization:
Plain Radiographs (Essential):
MRI (Standard for most arthroscopic indications):
MR Arthrography (Gold standard for labral pathology):
Instability Procedures:
| Clinical Scenario | Arthroscopic Procedure | Portal Configuration |
|---|---|---|
| Primary anterior instability, no bone loss | Arthroscopic Bankart repair | Posterior + Anterior + Anteroinferior |
| SLAP tear (symptomatic, young patient) | SLAP repair or biceps tenodesis | Posterior + Anterior + Anterosuperolateral |
| Posterior instability | Posterior labral repair | Posterior + Anterior + Posterolateral |
| Multidirectional instability | Capsular plication | Posterior + Anterior |
Rotator Cuff Procedures:
| Pathology | Procedure | Portal Configuration |
|---|---|---|
| Full-thickness tear | Arthroscopic cuff repair | Posterior + Lateral + Anterolateral |
| Partial articular-side tear greater than 50% | Complete and repair or transtendon repair | Posterior + Lateral + Anterior |
| Subacromial impingement | Subacromial decompression | Posterior subacromial + Lateral subacromial |
Biceps Procedures:
| Pathology | Procedure | Portal Configuration |
|---|---|---|
| Biceps tendinopathy | Tenotomy (older patient) | Posterior + Anterior (simple release) |
| Biceps tendinopathy | Tenodesis (younger, active) | Posterior + Anterior + Anterosuperolateral |
Principle: Posterior portal ALWAYS first, all other portals under direct vision.
Palpate the posterolateral corner of the acromion. This is your reference point. From this bony landmark, measure 2cm medially (toward spine) and 2cm inferiorly (toward axilla). This is the soft spot - a palpable depression.
Mark the soft spot with surgical marker. This portal will pass through infraspinatus muscle and posterior capsule to enter the glenohumeral joint, aiming toward the coracoid process anteriorly.
Insert 18-gauge spinal needle at marked site, aiming toward the coracoid (anterior and slightly superior direction). Angle slightly superior to avoid going inferiorly. You should feel capsule give way as needle enters joint. Inject saline to distend joint (30-60mL).
Remove needle. Make 1cm longitudinal or transverse stab incision with 11-blade at needle entry point. Use blunt dissection with hemostat to spread down to capsule if needed.
Insert blunt trocar with arthroscopic cannula through incision, aiming toward coracoid. Feel the capsule give way with gentle pressure. Do NOT force. Insert trocar/cannula into joint until you feel loss of resistance.
Remove trocar, insert 30-degree arthroscope through cannula. Connect camera, light source, and fluid inflow. Confirm intra-articular position by visualizing humeral head and glenoid. Orient scope so humeral head is on right side of screen, glenoid on left (in beach chair).
The posterior portal is the safest portal to create. It passes through infraspinatus muscle and enters the joint posteriorly. The suprascapular nerve is at risk if you go too medial (toward scapular spine), but standard portal placement 2cm medial to posterolateral acromion is safe.
Why posterior portal first?
The posterior portal is the foundation of shoulder arthroscopy.
| Complication | Incidence | Prevention | Management |
|---|---|---|---|
| Axillary nerve injury | 0.1-2% | Protect during anterior-inferior work; stay superior to 5 o'clock (right) or 7 o'clock (left); avoid excessive capsular release | Document postop, EMG at 6 weeks, most neurapraxias recover by 3-6 months; consider exploration if no recovery |
| Iatrogenic chondral injury | 1-5% | Gentle cannula insertion, visualize all portal creation, avoid excessive instrument manipulation | Document at time of surgery; debride loose fragments; may contribute to future arthritis |
| Infection | Less than 1% | Perioperative antibiotics, sterile technique | Arthroscopic washout, IV antibiotics, culture-directed therapy |
| Stiffness/adhesive capsulitis | 2-5% | Early passive ROM, appropriate postop protocol | Intensive physiotherapy, MUA if severe, arthroscopic capsular release if refractory |
| Fluid extravasation | Common (10-30%) | Monitor pump pressure (less than 60mmHg), limit OR time, recognize early | Most benign; airway compromise in beach chair position requires urgent management; compartment syndrome rare but possible |
| Rotator cuff iatrogenic injury | 1-3% | Portal placement under direct vision, lateral portal through supraspinatus (minimize trauma), avoid multiple passes | Document; may require repair if full-thickness created; counsel patient |
| Instrument breakage | Rare (less than 1%) | Use instruments properly, inspect before use, replace worn instruments | Retrieve all fragments arthroscopically or open; do not leave in joint |
| Failure of repair | 5-20% depending on procedure | Appropriate patient selection, meticulous technique, secure fixation, appropriate rehabilitation | Revision surgery if symptomatic; imaging to assess failure pattern |
Airway compromise from fluid extravasation is an emergency. Fluid can track from the shoulder to the neck and mediastinum in beach chair position, causing airway edema or compression. Monitor patient airway throughout procedure. If neck swelling noted, inform anesthesia immediately, consider early intubation if not already intubated, expedite procedure completion. Postoperative observation essential.
Prevention strategies:
Immediate Postoperative Care:
Sling Duration by Procedure:
| Procedure | Sling Duration | Rationale |
|---|---|---|
| Diagnostic arthroscopy | 24-48 hours comfort | Minimal tissue healing required |
| Subacromial decompression | 24-48 hours comfort | Early ROM encouraged |
| Bankart repair | 4-6 weeks | Labral healing time |
| Rotator cuff repair | 4-6 weeks | Tendon-to-bone healing |
| SLAP repair | 4-6 weeks | Superior labral healing |
| Capsular release (frozen shoulder) | 24-48 hours, early aggressive ROM | Prevent recurrence of adhesions |
Early Rehabilitation Principles:
Arthroscopic Bankart Repair:
Arthroscopic Rotator Cuff Repair:
| Procedure | Success Rate | Main Complication | Return to Activity |
|---|---|---|---|
| Arthroscopic Bankart | 85-95% | Recurrent instability 5-15% | 6 months to contact sport |
| Arthroscopic cuff repair | 80-95% clinical | Re-tear 10-40% | 3-6 months |
| Subacromial decompression | 80-90% | Stiffness 5-10% | 4-6 weeks |
| SLAP repair | 70-85% | Stiffness, persistent pain | 6 months to throwing |
Practice these scenarios to excel in your viva examination
"The examiner asks: 'Describe your technique for establishing portals for diagnostic shoulder arthroscopy.'"
"During shoulder arthroscopy for anterior instability, after establishing the posterior portal you have poor visualization of the anterior glenoid due to bleeding and cannot see clearly to create your anterior working portal. How do you proceed?"
"You are planning an arthroscopic Bankart repair for recurrent anterior shoulder instability. The examiner asks: 'Would you use beach chair or lateral decubitus positioning and why?'"
Posterior Portal Landmarks
Q: What are the correct landmarks for the posterior viewing portal in shoulder arthroscopy?
A: 2cm medial and 2cm inferior to the posterolateral corner of the acromion. This is the "soft spot" and represents the safest and most consistent entry point. The portal passes through infraspinatus muscle and posterior capsule to enter the glenohumeral joint, aiming toward the coracoid process anteriorly.
Axillary Nerve Protection
Q: Where does the axillary nerve run in relation to the glenoid and how do you protect it during shoulder arthroscopy?
A: The axillary nerve runs 5-7mm inferior to the glenoid rim at the anteroinferior capsule. To protect it during arthroscopic Bankart repair and anterior-inferior capsular work, stay superior to the 5 o'clock position on the right shoulder (or 7 o'clock on the left shoulder). Avoid excessive capsular release inferiorly and place anchors superior to this position.
Anterior Portal Gateway
Q: What is the safe anatomic gateway for the anterior working portal and what are its boundaries?
A: The rotator interval is the safe gateway. Boundaries are: superior border of subscapularis (inferior), anterior border of supraspinatus (superior), coracoid base (medial), and transverse humeral ligament over bicipital groove (lateral). The portal enters just lateral to the coracoid, passes through the rotator interval, and enters the joint near the biceps tendon origin.
Beach Chair Cerebral Perfusion
Q: What is the target blood pressure for shoulder arthroscopy in beach chair position and why?
A: Mean arterial pressure should be maintained greater than 70mmHg to prevent cerebral hypoperfusion and watershed infarcts in the upright position. This requires communication with anesthesia and blood pressure monitoring throughout the procedure. Hypotension in beach chair can lead to cerebral ischemia.
Portal Creation Sequence
Q: What is the correct sequence for shoulder arthroscopy portal creation and why?
A: Posterior portal is ALWAYS created first. This is the primary viewing portal and is created using palpable landmarks (2cm medial, 2cm inferior to posterolateral acromion). All subsequent portals (anterior, lateral, etc.) are created under direct arthroscopic visualization from the posterior portal using spinal needle localization. This minimizes risk of iatrogenic injury to neurovascular structures and rotator cuff.
Lateral Portal Anatomy
Q: The lateral (Neviaser) portal passes through which structure and what is the risk?
A: The lateral portal passes directly through the supraspinatus tendon to enter the glenohumeral joint. The risk is iatrogenic injury to the supraspinatus. This is minimized by: (1) creating the portal under direct visualization, (2) using smooth cannula insertion, (3) minimizing the number of passes through the tendon. The lateral portal is primarily used for rotator cuff repairs and superior labral work where access to the cuff tendon is already needed.
Epidemiology:
Shoulder arthroscopy is one of the most commonly performed orthopedic procedures in Australia, with over 40,000 procedures performed annually. The most common indications are rotator cuff repair, subacromial decompression, and anterior shoulder stabilization for instability.
Practice patterns:
Training requirements:
Shoulder arthroscopy is a core skill for Australian orthopedic trainees. Competence in:
These skills are expected for FRACS examination and independent practice.
Medicolegal considerations:
Australian guidelines:
High-Yield Exam Summary
