Posterior canal expansion for multilevel CSM and OPLL with preserved lordosis · advanced
- Indication requires preserved cervical lordosis (greater than 10 degrees) to permit cord drift-back; straight or kyphotic spines are contraindicated because the cord cannot migrate posteriorly without the posterior tension band intact.
- Preserve C2 and C7 muscular attachments (semispinalis cervicis and multifidus) — their detachment is the strongest predictor of post-operative axial neck pain and loss of lordosis; the C3-C6 spinous processes may be removed but C2 and C7 muscle origins must remain.
- Open-door technique creates a unilateral hinge at the junction of lamina and lateral mass on one side and a complete open trough on the contralateral side; the opened lamina is held elevated with mini-plates or sutures to the lateral mass.
- C5 palsy occurs in 5-10 percent of cases — most are transient (resolve within 6-12 months) but 1-2 percent remain permanent; risk factors include pre-operative severe cord compression, OPLL, and excessive cord shift greater than 3 mm on post-op MRI.
- Lordosis is mandatory: measure the C2-C7 Cobb angle on a standing lateral radiograph — less than 10 degrees or any kyphosis means laminoplasty will fail and the patient needs fusion or anterior surgery.
- Mark the C2 and C7 muscular insertions before elevation and re-attach or preserve the C2 semispinalis insertion on the C2 spinous process; this reduces axial pain from 40 percent to less than 15 percent.
- The open trough must reach the lamina-lateral mass junction without entering the facet joint; the hinge side trough is thinned to 50 percent depth leaving a greenstick hinge that opens 8-12 mm.
- Mini-plate fixation (standard now) uses 5-7 mm screws into the lateral mass and lamina edge; avoid over-distraction that fractures the hinge or under-correction that leaves residual stenosis.
When & Why
Indication. Symptomatic multilevel cervical cord compression — cervical spondylotic myelopathy (CSM) or ossification of the posterior longitudinal ligament (OPLL) across three or more levels — in a patient who still has preserved cervical lordosis (C2-C7 Cobb angle greater than 10 degrees), minimal axial neck pain, and disease that has progressed despite conservative care. The whole rationale rests on that lordosis: once the canal is expanded, the cord drifts posteriorly 2-4 mm away from the anterior compression, without resecting it. Absolute indications
- Multilevel (3 or more levels) CSM with preserved cervical lordosis (C2-C7 Cobb greater than 10 degrees).
- OPLL with multilevel cord compression and lordosis preserved.
- Minimal pre-existing axial neck pain (VAS less than 4/10) — patients with severe axial pain are better served by fusion.
- Progressive myelopathy (Nurick grade 2 or higher, or mJOA less than 14) despite conservative management. Relative indications
- Patients who wish to preserve cervical motion and avoid fusion-related adjacent segment disease.
- OPLL with segmental or continuous type where anterior surgery would require extensive corpectomy.
- Poor anterior approach candidates (prior anterior surgery, radiation, tracheostomy, high BMI). Contraindications — absolute
- Cervical kyphosis or straight alignment (C2-C7 Cobb less than 10 degrees) — the cord cannot drift posteriorly.
- Severe axial neck pain (greater than 6/10) with facet arthropathy — laminoplasty does not address posterior column pain generators.
- Single-level disease better treated by ACDF or disc arthroplasty. Contraindications — relative
- Prior posterior surgery with extensive scarring.
- Active infection or tumour requiring resection rather than decompression.
- Severe osteoporosis increasing hinge fracture risk. The one decision that matters — which posterior/anterior strategy:
Multilevel CSM or OPLL with preserved lordosis (C2-C7 Cobb greater than 10 degrees) and minimal axial pain. Preserves 30-50 percent of cervical motion and avoids fusion-related adjacent segment disease.
When cervical kyphosis or straight alignment is present, axial pain is significant with facet arthropathy, or a fixed deformity needs correction. Sacrifices motion but controls alignment.
Focal 1-3 level disease, lost lordosis or focal kyphosis, or large disc/OPLL requiring direct anterior resection (greater than 50 percent canal compromise). Higher dysphagia and recurrent laryngeal nerve risk.
- Laminoplasty
- Lordosis greater than 10 degrees
- Laminectomy-fusion
- Any alignment (corrects kyphosis)
- Anterior (ACDF/Corpectomy)
- Lordosis or correctable kyphosis
- Laminoplasty
- 3 or more levels
- Laminectomy-fusion
- 3 or more levels
- Anterior (ACDF/Corpectomy)
- 1-3 levels ideal
- Laminoplasty
- Minimal (VAS less than 4)
- Laminectomy-fusion
- Significant facet pain
- Anterior (ACDF/Corpectomy)
- Minimal posterior pain
- Laminoplasty
- Yes (30-50 percent retained)
- Laminectomy-fusion
- No (fused)
- Anterior (ACDF/Corpectomy)
- Variable (arthroplasty option)
- Laminoplasty
- 5-10 percent
- Laminectomy-fusion
- 3-8 percent
- Anterior (ACDF/Corpectomy)
- 1-3 percent
- Laminoplasty
- Hinge fracture, axial pain
- Laminectomy-fusion
- Pseudoarthrosis, hardware failure
- Anterior (ACDF/Corpectomy)
- Dysphagia, RLN injury, subsidence
Consent specifically for C5 palsy (5-10 percent, most transient), axial neck pain (10-20 percent even with muscle preservation), hinge fracture, incomplete decompression, infection (under 2 percent), and the possible need for revision fusion. Setup. Prone on a Jackson table or in a Mayfield head holder with slight reverse Trendelenburg (15-20 degrees) to reduce venous bleeding, head neutral or in slight flexion to open the interlaminar spaces. Intraoperative neuromonitoring (MEP, SSEP, free-running EMG) is mandatory. General endotracheal anaesthesia; maintain MAP greater than 80 mmHg for cord perfusion; cell saver available for an anticipated blood loss of 200-400 mL. Loupe or microscope magnification is mandatory for trough creation.
The Operation
The goal: open the posterior canal by hinging the laminae outward, letting the cord drift back 2-4 mm off the anterior compression, while preserving the posterior muscle tension band (C2 and C7 attachments) so motion and lordosis are kept. The exposure — a muscle-sparing posterior cervical approach — is the heart of the operation and is laid out in full as the first steps below (and in depth on the posterior cervical approach page).

Operative sequence
- Prone on a Jackson table or Mayfield head holder, slight reverse Trendelenburg (15-20 degrees) to reduce venous bleeding; head neutral or in slight flexion to open the interlaminar spaces; arms tucked, all pressure points padded.
- Intraoperative neuromonitoring (MEP, SSEP, free-running EMG) on throughout; maintain MAP greater than 80 mmHg for cord perfusion.
- Midline skin incision from C2 to C7.
- Subperiosteal elevation strictly limited to the C3-C6 laminae using a Cobb elevator.
- Identify and preserve the semispinalis cervicis insertion on the C2 spinous process (the primary posterior tension band for head extension) and the multifidus on C7 (deep segmental stabiliser); the C2 and C7 spinous processes remain intact.
- Expose the lamina-lateral mass junction bilaterally from C3 to C6 — the critical landmark for every trough — without entering the facet joint, which lies immediately lateral.
- Under loupe or microscope magnification, mark the troughs at the lamina-lateral mass junction bilaterally (the lamina is 3-5 mm thick at C3-C6).
- Hinge side (usually the patient's left for a right-handed surgeon): thin with a high-speed burr to approximately 50 percent cortical depth, creating a greenstick hinge.
- Open side: drill completely through the lamina into the epidural space, then complete with a Kerrison rongeur, dividing the ligamentum flavum (which attaches to the lamina undersurface and must be divided to allow elevation).
- The open trough must reach the medial border of the lateral mass without entering the facet joint; the hinge trough is parallel and symmetric.
- Remember the vertebral artery lies in the transverse foramen 1.5-2 cm lateral to the lateral mass — troughs must never extend into the foramen.
- Gently elevate the opened laminae with a Penfield or lamina elevator in a controlled, gradual manner.
- Aim for 8-12 mm of opening at the open side; the cord occupies 50-70 percent of the canal in severe stenosis, so even modest expansion allows 2-4 mm of posterior drift.
- Confirm cord decompression with intraoperative ultrasound before fixation.
- Avoid sudden or excessive elevation that causes cord shift greater than 4 mm — this stretches the short, horizontally exiting C5 root and is the mechanism of C5 palsy.
- Apply pre-contoured mini-plates (usually 8-12 mm length) spanning from the elevated lamina to the lateral mass.
- Fix with 5-7 mm lateral mass screws (trajectory 25-30 degrees lateral, 15 degrees cephalad) and 4-5 mm lamina screws.
- Typically plate C4, C5 and C6; the remaining levels may be secured with sutures or left as floating hinges if stable.
- Aim for about 10 mm of opening and confirm with a calibrated spreader before plating — over-distraction of the open side risks hinge fracture, under-correction leaves residual stenosis.
- The French-door technique splits the spinous processes in the midline and creates bilateral hinges at the lamina-lateral mass junctions; the two hemilaminae are elevated symmetrically, creating a wider central canal.
- Fixation options: central suture or bone-block spacer between the split spinous processes, bilateral mini-plates on each side, or titanium/hydroxyapatite spacers in the open gutters.
- Advantages: more symmetric canal expansion; potentially lower hinge fracture rate on any single side.
- Disadvantages: longer operative time; risk of spinous process fracture; technically more demanding in OPLL with asymmetric compression.
- Meticulous bipolar haemostasis of the prominent epidural venous plexus to prevent post-operative haematoma.
- Layered closure with absorbable sutures to the preserved muscle fascia; no drain is routinely required.
- Skin closure with subcuticular absorbable suture.
Fixation options. After elevating the door, choose how to hold it open:
- Advantages
- Rigid immediate stability; low hinge failure; early mobilisation
- Disadvantages
- Cost; slight increase in operative time
- Current use
- Preferred in most modern series
- Advantages
- Low cost; simple
- Disadvantages
- Less rigid; higher late hinge closure or fracture
- Current use
- Still used in resource-limited settings
- Advantages
- Biologic; no hardware
- Disadvantages
- Donor-site morbidity; resorption; displacement risk
- Current use
- Less common now
- Advantages
- Symmetric expansion
- Disadvantages
- Longer surgery; spinous process fracture risk
- Current use
- Selected OPLL cases
Before any bone work, three structures define the danger zones. First, the C2 semispinalis cervicis and C7 multifidus insertions — detaching them destroys the posterior tension band and drives post-operative kyphosis (20-30 percent if sacrificed versus under 5 percent preserved) and axial pain (15-40 percent versus under 10 percent); elevate only C3-C6. Second, the facet joint, lying immediately lateral to the lamina-lateral mass junction — an open trough that strays lateral breaches the facet and destabilises the segment. Third, the vertebral artery, 1.5-2 cm lateral in the transverse foramen — troughs must never extend into the foramen. Throughout elevation, watch for direct cord trauma and excessive posterior shift (greater than 4 mm); neuromonitoring (MEP/SSEP) is mandatory and steroids should be ready.
Before any elevation, mark the semispinalis cervicis insertion on C2 and the multifidus on C7 — these are the posterior tension band. Elevate subperiosteally only from C3 to C6 with a Cobb elevator, leaving the C2 and C7 attachments completely undisturbed. This single step is the most important measure against post-operative kyphosis and axial pain.
Plate C4, C5 and C6 routinely; C3 and C7 can be left with suture or bone-block elevation if the hinge is stable. Aim for about 10 mm of opening and confirm with a calibrated spreader before plating — over-distraction of the open side risks hinge fracture, while under-correction leaves residual stenosis.
Aftercare & Complications
Rehabilitation | Phase | Timing | Immobilisation | Therapy | |-------|--------|----------------|---------| | 1 | Day 0–3 | Soft collar for comfort only | Neurological checks every 2 hours for the first 24 hours (C5 palsy window); isometric neck exercises from day 1 | | 2 | Week 1–6 | Collar for 2 weeks only | Gentle active range of motion from week 2; hand therapy for myelopathy-related dexterity deficits | | 3 | Return to function | Night splint if needed | Driving at 4–6 weeks; light work 6–8 weeks; heavy manual labour or contact sports 3–6 months | Most patients return to desk work by 6-8 weeks. Full neurologic recovery is assessed at 6 and 12 months. Prolonged collar use is avoided — it increases stiffness and muscle atrophy without aiding recovery.
- Incidence & recognition
- 5-10 percent overall (up to 15 percent with OPLL); day 2-7 deltoid and biceps weakness, often with C5 dermatome sensory loss
- Prevention
- Limit opening to 8-10 mm; prophylactic C4-C5 and C5-C6 foraminotomy in OPLL; preserve ligamentum flavum attachments
- Management
- MRI to exclude haematoma or hinge fracture; physiotherapy, short oral steroids, EMG at 6 weeks; 80-90 percent resolve by 6-12 months; tendon transfer for the 1-2 percent permanent deficit
- Incidence & recognition
- Post-op kyphosis in 20-30 percent if muscles are sacrificed versus under 5 percent when preserved; recurrent myelopathy once kyphosis exceeds 10 degrees
- Prevention
- Preserve C2 semispinalis cervicis and C7 multifidus; subperiosteal elevation only to C3-C6
- Management
- Revision fusion if kyphosis progresses or myelopathy recurs
- Incidence & recognition
- Rare; direct trauma from Kerrison or elevator, or reperfusion/root stretch from sudden shift
- Prevention
- Microscope or loupes; gentle controlled elevation; neuromonitoring (MEP/SSEP) mandatory; steroids ready
- Management
- Immediate steroids; consider staged or limited opening in ultra-severe stenosis
- Incidence & recognition
- 2-5 percent; floating lamina on post-op CT, may be asymptomatic or unstable
- Prevention
- Thin hinge to 50 percent cortical depth under loupe; test greenstick opening before plating; avoid over-distraction
- Management
- Stable fracture: observe; complete fracture: bilateral mini-plate or convert to laminectomy-fusion; rigid collar 6-12 weeks
- Incidence & recognition
- 3-8 percent; persistent or recurrent symptoms with residual compression on post-op CT/MRI
- Prevention
- Extend the open trough fully to the lateral mass junction; open 10-12 mm; confirm with ultrasound; address focal anterior pathology
- Management
- Revision anterior surgery or posterior fusion depending on alignment and pathology
- Incidence & recognition
- 10-20 percent even with muscle preservation (chronic in 5-10 percent)
- Prevention
- Preserve C2/C7 muscles; limit dissection to C3-C6; early isometrics; avoid prolonged collar
- Management
- Physiotherapy, NSAIDs, trigger point injections; rarely fusion
- Incidence & recognition
- Under 2 percent
- Prevention
- Standard prophylaxis
- Management
- Antibiotics and possible washout
Viva & Exam Focus
LORDOSISLORDOSIS — patient selection and muscle preservation
C5PALSYC5 PALSY — prevention and management
Clinical Decision Scenarios
Practise clinical reasoning and management decisions out loud
“A 62-year-old man with multilevel cervical spondylotic myelopathy has a C2-C7 Cobb angle of 18 degrees on standing lateral radiograph. He has progressive gait instability and hand numbness but minimal axial neck pain. MRI shows cord compression from C3 to C6 with preserved lordosis. What surgical approach do you recommend and why?”
“A 58-year-old woman with continuous-type OPLL from C3 to C6 undergoes open-door laminoplasty. On post-operative day 3 she develops new right deltoid and biceps weakness (MRC 3/5) with preserved hand intrinsics and no leg deterioration. What is the most likely diagnosis, expected natural history, and your management plan?”
“During open-door laminoplasty at C5 the hinge fractures completely while elevating the lamina. The lamina is now floating and unstable. How do you manage this intra-operatively and what are the long-term implications?”
Indication — lordosis is everything
- Multilevel (3 or more levels) CSM or OPLL with preserved lordosis (C2-C7 Cobb greater than 10 degrees)
- Minimal axial neck pain (VAS less than 4); severe facet pain favours fusion
- Contraindicated in kyphosis, a straight spine, or when anterior pathology needs direct resection
- Patient preference for motion preservation over fusion
Critical anatomy — muscle preservation
- Semispinalis cervicis inserts on the C2 spinous process — the primary posterior tension band
- Multifidus inserts on C7 — segmental stabiliser; detach only the C3-C6 laminae
- The C5 root has the shortest intradural length and most horizontal exit — highest tethering risk
- The lamina-lateral mass junction is the trough landmark; avoid entering the facet joint
Open-door technique — key steps
- 1. Subperiosteal exposure limited to C3-C6; preserve C2 and C7 muscle insertions
- 2. Hinge trough thinned to 50 percent depth for a greenstick opening
- 3. Open trough completed through lamina and ligamentum flavum to the lateral mass junction
- 4. Controlled elevation 8-12 mm; confirm cord drift with ultrasound
- 5. Mini-plate fixation (C4-C6 typical) with 5-7 mm lateral mass screws
- 6. No prolonged collar; early isometric exercises from day 1
C5 palsy — prevention and natural history
- Incidence 5-10 percent; higher in OPLL and severe pre-op compression
- Risk factors: cord shift greater than 3 mm, OPLL, pre-op cord compression ratio less than 0.4
- 80-90 percent resolve by 12 months; permanent deficit 1-2 percent
- Prevention: limit opening to 8-10 mm; consider prophylactic C4-C5/C5-C6 foraminotomy in OPLL
Complications — incidence and management
- Axial neck pain: 10-20 percent (muscle preservation reduces to under 10 percent)
- Hinge fracture: 2-5 percent; convert to bilateral plating or fusion if complete
- Incomplete decompression: 3-8 percent; revision anterior or posterior fusion
- Infection: under 2 percent; standard prophylaxis and wound care
Post-op protocol
- Neurological checks every 2 hours for 24 hours (C5 palsy window)
- Soft collar for comfort only; remove for isometric exercises day 1
- Driving 4-6 weeks; light work 6-8 weeks; heavy labour 3-6 months
- MRI at 6-12 months if persistent or recurrent myelopathy symptoms
Laminoplasty versus alternatives
- Laminectomy-fusion: when kyphosis is present or axial pain is significant; loses motion
- Anterior surgery: 1-3 levels, focal pathology, or lost lordosis; higher dysphagia risk
- Laminoplasty advantage: motion preservation, lower adjacent segment disease, lower dysphagia
Background & Evidence
Relevant posterior cervical anatomy. The cervical lamina forms the posterior arch of the canal and is 3-5 mm thick at C3-C6; the C7 lamina is the largest and thickest, while the C2 lamina is short and stout and carries the semispinalis cervicis insertion. The lamina-lateral mass junction is the critical landmark for trough creation, with the facet joint lying immediately lateral. The semispinalis cervicis (inserting on C2) and the multifidus (inserting on C7 and the upper thoracic spinous processes) form the posterior tension band; their detachment leads to loss of dynamic lordosis, facet overload, and progressive kyphosis in 20-40 percent. The ligamentum flavum attaches to the lamina undersurface and must be divided at the open trough; the dentate ligaments tether the cord laterally, so excessive posterior shift stretches the C5 and C6 roots. The C5 root exits most horizontally with the shortest intradural length (about 10-12 mm), which explains its particular vulnerability to tethering during drift-back. The cord occupies 50-70 percent of the canal in severe stenosis, so a canal expansion of 8-12 mm allows 2-4 mm of posterior drift. The vertebral artery lies within the transverse foramen 1.5-2 cm lateral to the lateral mass, and the epidural venous plexus is prominent — demanding meticulous bipolar haemostasis. Key evidence. Hirabayashi (1983) described expansive open-door laminoplasty, reporting 83 percent neurologic improvement at five years in the original series; the technique remains the foundation, with modern modifications focused on muscle preservation and rigid mini-plate fixation to reduce axial pain. On motion preservation, laminoplasty retains 30-50 percent of cervical motion and avoids the fusion-related complications of pseudoarthrosis (5-15 percent) and adjacent segment disease; a meta-analysis (Yuan, 2019) found laminoplasty gave better range-of-motion preservation and fewer complications than laminectomy-fusion for multilevel CSM, with equivalent neurologic recovery. On the dominant complication, a meta-analysis (Shou, 2015) found an overall C5 palsy incidence of 5.8 percent, with OPLL and post-operative cord shift identified as the key risk factors — underpinning the modern practice of limiting opening to 8-10 mm and considering prophylactic foraminotomy in high-risk OPLL. Comparing the two techniques, Nakashima (2014) found equivalent neurologic recovery between open-door and French-door laminoplasty, with the French-door showing a slightly lower hinge fracture rate but a longer operative time.
References
Expansive open-door laminoplasty for cervical spinal stenotic myelopathy
- Original description of open-door laminoplasty in 40 patients with 5-year follow-up
- 83 percent neurologic improvement; established the principle of posterior canal expansion with preserved motion
Comparison of laminectomy and fusion vs laminoplasty in the treatment of multilevel cervical spondylotic myelopathy: A meta-analysis
- Meta-analysis comparing laminoplasty to laminectomy and fusion for multilevel CSM
- Laminoplasty was associated with better range of motion preservation and fewer complications
Prevalence of C5 nerve root palsy after cervical decompressive surgery: a meta-analysis
- Meta-analysis finding overall C5 palsy incidence of 5.8 percent
- OPLL and post-operative cord shift were identified as risk factors for C5 palsy
Comparative effectiveness of open-door laminoplasty versus French-door laminoplasty in cervical compressive myelopathy
- Comparison of open-door versus French-door techniques
- Equivalent neurologic recovery; French-door had slightly lower hinge fracture rate but longer operative time
