Prone positioning | Saphenous nerve | Popliteal bundle | Buttress plating
- Posteromedial and posterior coronal split fragments occur in 10 to 15 percent of tibial plateau fractures and cannot be adequately buttressed through a standard anteromedial approach.
- Prone (or floppy lateral) positioning is required — not supine — for true posterior access; prone lets gravity retract the gastrocnemius.
- The superficial internervous plane runs between the pes anserinus (femoral and obturator nerves) anteriorly and the medial head of gastrocnemius (tibial nerve) posteriorly.
- The saphenous nerve and greater saphenous vein lie in the subcutaneous fat along the incision — identify and protect them before dividing fascia.
- The popliteal artery, vein and tibial nerve lie immediately posterior to the plateau — gentle retraction only, never metal retractors on the bundle.
- A buttress plate on the posteromedial surface is mandatory to resist posterior displacement under axial load.
When & Why
What it exposes. The posteromedial approach gives direct access to the posteromedial tibial plateau and posterior coronal split fragments of the medial column — fragments that occur in approximately 10 to 15 percent of tibial plateau fractures and are frequently missed on plain radiographs. It is the workhorse exposure for buttress plating of posteromedial split and split-depression fragments. Why posterior (and not anteromedial). A standard anteromedial approach cannot place a true posterior buttress plate. Posteromedial fragments displace posteriorly under axial load, so a buttress plate on the posterior surface is biomechanically required to resist re-displacement. The posteromedial approach allows anatomic reduction under direct vision and correct buttress-plate placement. Position. The patient is placed prone on a radiolucent table with the knee flexed 20 to 30 degrees over a bump — gravity retracts the gastrocnemius and gives direct posterior access. The leg is prepared and draped free, and a tourniquet is applied but usually not inflated unless bleeding obscures vision. The floppy lateral position (affected side up, knee flexed) is an alternative that reaches both posteromedial and posterolateral columns without repositioning, useful when combined approaches are planned. Landmarks. Palpate and mark the posteromedial border of the proximal tibia, the medial head of gastrocnemius, the pes anserinus insertion on the medial tibia, the joint line (with the knee flexed), and the fibular head (to orient the popliteal fossa). Approach variants.
- Description
- Along the posteromedial border of the proximal tibia
- Best use
- Most common — isolated posteromedial fragments
- Description
- Combined with a medial exposure
- Best use
- Bicondylar fractures
- Description
- Midline posterior incision for both columns
- Best use
- Complex posterior patterns
The Exposure
Work down through the layers along the posteromedial border, protecting the saphenous nerve and vein superficially, then develop the pes-anserinus to medial-gastrocnemius interval to reach the posterior cortex while guarding the popliteal bundle.

Exposure sequence
- Make a longitudinal incision along the posteromedial border of the proximal tibia, beginning at the level of the joint line and extending 10 to 12 centimetres distally — extensile proximally or distally as the fracture demands.
- Position it so the incision lies over the fragment and allows a buttress plate to be slid onto the posterior surface.
- In the subcutaneous fat, identify the saphenous nerve and greater saphenous vein running along the posteromedial border; gently retract them anteriorly and protect them with vessel loops.
- Always palpate and visually confirm the nerve position before dividing fascia — failing to identify it here is the commonest cause of iatrogenic injury.
- Expose the fascia over the pes anserinus and medial gastrocnemius, then incise the fascia along the anterior border of the medial gastrocnemius.
- Identify the pes anserinus tendons and retract them anteriorly; develop the interval between the pes anserinus and medial gastrocnemius bluntly with scissors or a finger — this plane is relatively bloodless.
- The superficial plane is a true internervous plane: pes anserinus (sartorius from the femoral nerve; gracilis and semitendinosus from the obturator nerve) anteriorly versus the medial head of gastrocnemius (tibial nerve) posteriorly.
- Retract the medial head of gastrocnemius laterally to deepen the exposure.
- Elevate the soleus origin off the posterior tibia subperiosteally from medial to lateral, exposing the posterior cortex of the proximal tibia.
- The deep plane is between the medial gastrocnemius and soleus (both tibial nerve), but it is safe because the motor branches enter the muscles proximally and the dissection stays distal to them.
- Incise the posterior capsule carefully under direct vision — mind the posterior horn of the medial meniscus — to visualise the posteromedial articular surface.
- Reduce the fragment under direct vision and apply a buttress plate to the posteromedial surface with screws directed anteriorly into the fragment.
The popliteal artery, vein and tibial nerve lie in the popliteal fossa immediately posterior to the tibial plateau. Stay anterior to the gastrocnemius, place every deep retractor under direct vision, retract gently and laterally, never rest a metal retractor directly on the bundle, and release retractors every 20 minutes. Popliteal artery injury is limb-threatening.
A posteromedial fragment displaces posteriorly under axial load, so a buttress plate on the posterior surface is mandatory — a lag screw alone, or an anteromedial plate, will not resist posterior displacement.
Dangers & Extensions
Structures at risk, by layer
- Structure at risk
- Saphenous nerve and greater saphenous vein
- Protection
- Identify early before dividing fascia; vessel loops; retract anteriorly; avoid excessive traction
- Structure at risk
- Small perforating vessels (no major structures)
- Protection
- Bipolar haemostasis as encountered
- Structure at risk
- Popliteal artery, popliteal vein and tibial nerve
- Protection
- Gentle lateral retraction only; never place metal retractors on the bundle; release retractors every 20 minutes
- Structure at risk
- Posterior capsule and posterior horn of the medial meniscus
- Protection
- Incise carefully under direct vision
The saphenous nerve is the structure most often injured if it is not actively identified; injury causes medial calf sensory loss and possible neuroma pain. The popliteal artery is the most serious — injury can result in limb loss. Tibial nerve injury causes plantarflexion weakness and sensory loss on the sole. Extensile options. Extend proximally along the medial border of the gastrocnemius to expose more of the posterior femoral condyle (protect the saphenous nerve again during this extension). Extend distally along the posteromedial border of the tibia, further elevating the soleus, taking care to avoid the posterior tibial artery and tibial nerve as they course distally. Closure. Close the posterior capsule if it was opened; the soleus origin is not repaired; close the fascia loosely to avoid compartment syndrome; close subcutaneous tissue in layers; skin with interrupted nylon or staples. Place a drain if dissection was extensive.
Procedures Through This Approach
- Tibial plateau ORIF — open reduction and internal fixation of isolated posteromedial tibial plateau fractures.
- Buttress plating of posteromedial split or split-depression fragments.
- Fixation of posterior coronal plane fractures of the medial plateau.
- Combined approaches for bicondylar fractures, used with the anterolateral approach.
- Revision surgery for posteromedial malunion or nonunion.
- Bone grafting of posteromedial metaphyseal defects.
Viva & Exam Focus
POSTEROMEDPOSTEROMED — the posteromedial plateau exposure
Clinical Decision Scenarios
Practise clinical reasoning and management decisions out loud
“A 45-year-old male sustains a Schatzker IV tibial plateau fracture with a large posteromedial split fragment after a motor vehicle collision. CT confirms greater than 5 millimetres of articular step-off and posterior displacement of the fragment. What approach would you use and why?”
“During a posteromedial approach you encounter brisk bleeding from the deep plane. What is your immediate management and which structure is most likely injured?”
“A patient develops numbness on the medial calf and inability to plantarflex the ankle after a posteromedial approach. What structures were injured and how could this have been prevented?”
Positioning
- Prone with the knee flexed 20–30 degrees over a bump
- Floppy lateral alternative for combined approaches
- Tourniquet applied but rarely inflated
- Leg draped free for manipulation
Landmarks
- Posteromedial border of the proximal tibia
- Medial head of gastrocnemius
- Pes anserinus insertion
- Joint line with the knee flexed
Internervous plane
- Superficial: pes anserinus (femoral/obturator) versus medial gastrocnemius (tibial)
- Deep: medial gastrocnemius versus soleus (both tibial but safe distal to the motor branches)
- A true internervous plane superficially
Dangers
- Subcutaneous: saphenous nerve and greater saphenous vein
- Deep: popliteal artery, vein and tibial nerve
- Never place metal retractors on the popliteal bundle
- Release retractors every 20 minutes
Procedures
- Buttress plating of posteromedial split fractures
- Fixation of posterior coronal plane fractures
- Combined approaches for bicondylar fractures
- Revision for posteromedial malunion
Closure
- Posterior capsule closed if opened
- Fascia closed loosely
- Drain if dissection was extensive
- Skin with nylon or staples
References
Stabilization of the posteromedial fragment in bicondylar tibial plateau fractures
- Mechanical study demonstrating dual plating provides superior stability for posteromedial fragments compared with a single lateral locking plate
Combined approaches for fixation of Schatzker type II tibial plateau fractures involving the posterolateral column
- Prospective study showing combined posterior approaches improve reduction quality and outcomes for complex tibial plateau fractures involving the posterior columns
A surgical protocol for bicondylar four-quadrant tibial plateau fractures
- Described a systematic protocol using combined anterolateral and posteromedial approaches for four-quadrant bicondylar fractures with good clinical results
The application of a three-column internal fixation system with anatomical locking plates on comminuted fractures of the tibial plateau
- Demonstrated that three-column fixation with posteromedial buttress plating achieves stable reduction and good function in comminuted tibial plateau fractures
