Aseptic loosening after total hip replacement Β· Paprosky bone-loss classification drives reconstruction
- Aseptic loosening is diagnosed by progressive pain (thigh pain equals femoral, groin pain equals acetabular), radiographic migration greater than 2mm, progressive radiolucent lines, and osteolysis from wear debris.
- MANDATORY pre-revision infection workup using the 2018 ICM/MSIS scoring: aspirate synovial WBC greater than 3000 cells/Β΅L (3 pts), PMN greater than 80 percent (2 pts), positive alpha-defensin (3 pts), synovial CRP greater than 6.9mg/L (1 pt), with serum CRP greater than 1mg/dL, ESR greater than 30mm/hr and D-dimer greater than 860ng/mL; hold cultures 14 days. The 2018 criteria reach 97.7 percent sensitivity and 99.5 percent specificity versus 79 percent for MSIS 2011. ESR and CRP alone are inadequate to exclude infection.
- Paprosky classification is essential for planning: Acetabular (Types I to IIIB based on rim, columns and migration) and Femoral (Types I to IV based on metaphyseal and diaphyseal bone loss).
- Reconstruction goals: 40 to 50 percent host bone contact, restore the anatomic hip center, place the cup in the Lewinnek safe zone (40 to 45 degrees inclination, 15 to 20 degrees anteversion), and achieve stable fixation to prevent migration.
When & Why
Indication. Symptomatic aseptic loosening of a total hip replacement that has failed non-operative management (activity modification, NSAIDs, walking aids). The loosening is shown by progressive pain with activity β thigh pain points to the femoral component, groin pain to the acetabular component β together with radiographic signs: component migration greater than 2mm, progressive radiolucent lines greater than 2mm wide at the bone-implant interface, component subsidence on serial films, and osteolysis from wear debris. Constant pain at rest, fevers, chills, night sweats or a wound problem instead raise the spectre of infection. The infection gate is mandatory. Before labelling any loosening "aseptic", periprosthetic joint infection must be excluded, because infection changes the entire operation (a staged revision rather than a single-stage reconstruction). ESR and CRP alone are inadequate β they carry roughly a 30 percent false-negative rate. The workup uses the validated 2018 International Consensus Meeting (ICM)/MSIS scoring system (97.7 percent sensitivity, 99.5 percent specificity), built from serum and synovial markers plus culture. Serum markers β CRP greater than 1mg/dL (2 points), D-dimer greater than 860ng/mL (2 points), ESR greater than 30mm/hr (1 point). Synovial aspirate (the key investigation) β WBC greater than 3000 cells/Β΅L (3 points), alpha-defensin positive (3 points), leukocyte esterase positive (3 points), PMN greater than 80 percent (2 points), synovial CRP greater than 6.9mg/L (1 point). Cultures must be held for 14 days for slow-growing organisms such as Cutibacterium acnes. Scoring β a sinus tract or two positive cultures are major criteria diagnostic of infection; otherwise an aggregate score of 6 or more defines infection. If equivocal β repeat the aspiration, add an Indium-111 WBC scan (about 90 percent sensitivity) or FDG-PET, and plan intra-operative tissue cultures (5 to 6 samples) with sonication of explanted components. If infection is confirmed, management is entirely different β a two-stage revision (explant, antibiotic spacer, 6 weeks of intravenous antibiotics, then reimplantation after the infection is eradicated). Preoperative assessment. Standard films (AP pelvis, lateral hip, full femur for long-standing loosening) define the bone loss; CT with 3D reconstruction better characterises Paprosky III defects and aids implant planning; MARS MRI assesses soft tissue (abductor quality) where metal artefact must be reduced. The bone loss is then classified with the Paprosky system (full definitions in Background & Evidence) β this dictates reconstruction. Plan the implants and the blood. Order the primary implant choice plus multiple sizes and backup options (augments, cages, modular tapered stems, strut grafts) so the correct construct is available whatever the intra-operative bone loss turns out to be β it is often worse than the imaging suggests. Revision carries a 30 to 50 percent transfusion rate, so blood management is part of the plan: preoperative haemoglobin optimisation (target greater than 120g/L, iron if ferritin is low), tranexamic acid 15 to 20mg/kg at induction repeated at 3 hours, cell saver, type and cross 2 to 4 units, and a restrictive transfusion threshold (Hb less than 70g/L, or less than 80g/L with symptoms). Consent honestly for the realities of revision: infection 2 to 5 percent, dislocation 10 to 15 percent, sciatic nerve palsy 2 to 5 percent, transfusion 30 to 50 percent, re-revision 10 to 15 percent at 10 years, and overall 10-year survival of 80 to 90 percent (versus 95 to 98 percent for a primary). Frame it as salvage for pain relief and function, not a return to high-impact activity. Setup. Lateral or supine depending on approach, on a radiolucent table with intra-operative fluoroscopy available. Reuse the previous surgical approach when possible β it is usually extensile in revision. General or regional anaesthesia with multimodal analgesia.
The Operation
The goal: exclude infection, expose the hip through the previous approach, identify and protect the sciatic nerve early, remove both loose components while preserving every scrap of host bone, curette all osteolysis to bleeding bone, and reconstruct the acetabulum and femur to a stable construct in the anatomic hip center. The exposure β laid out in full below and in depth on the posterior (Moore/Southern) approach to the hip page β is the heart of the operation.

Operative sequence
- Lateral or supine on a radiolucent table; fluoroscopy available throughout.
- Reuse the previous approach when possible to preserve soft-tissue vascularity and avoid creating new tissue planes.
- Tranexamic acid 15 to 20mg/kg intravenously at induction (repeat at 3 hours); cell saver set up; meticulous haemostasis and hypotensive anaesthesia where appropriate.
- Use the most posterior of any previous incisions for posterior access. Elliptically excise the old scar with 1 to 2mm margins to healthy dermis; thin scarred skin warns of higher dehiscence risk.
- Extend proximally toward the posterior superior iliac spine for acetabular access and distally along the femoral shaft for femoral access β total length typically 18 to 25cm (versus 10 to 15cm for a primary).
- Incise the thickened, scarred fascia lata in line with the previous surgery, matching the skin length.
- Split gluteus maximus in line with its fibres (a true internervous plane). In revision these planes are often obliterated by fibrosis β work patiently with sharp dissection; avoid blunt dissection, which tears tissue and increases bleeding.
- Extensive scar release is almost always required: the capsule is thick, contracted and adherent, and the short external rotators are frequently absent or severely atrophic.
- Palpate and identify the sciatic nerve early, posterior to the hip capsule; it may need to be dissected free of encasing scar.
- Pass a vessel loop or protected retractor around it. Nerve palsy risk is 2 to 5 percent in revision (versus 0.5 to 2 percent in a primary), driven by scar encasement, traction from lengthening, direct trauma and thermal injury.
- If the nerve cannot be clearly identified, proceed very cautiously and stay anterior to its expected location. Use protected (sleeved) retractors, avoid excessive traction, limit lengthening to less than 2cm (palsy risk rises exponentially beyond this), and take care with the burr near the posterior cortex.
- Complete the capsulotomy and scar release to deliver the femoral head/proximal femur.
- Confirm stability of exposure and proceed to component removal.
- Remove the modular liner first (an extractor or osteotome); inspect its wear pattern (eccentric wear suggests malposition or impingement).
- Loose cup: it often levers out with curved osteotomes.
- Well-fixed cup: insert curved osteotomes between cup and bone around the entire circumference, working sequentially with gentle taps; stay ON the metal, not the bone β bone preservation is paramount. Use a specialised extraction system (slap hammer) if needed. Remove screws from the outer surface, or cut them off inside the cup / burr the heads if stripped. For a cemented cup, remove cement with a high-speed burr and flexible osteotomes.
- Curette ALL osteolysis β polyethylene debris (grey/white rubbery), granulation tissue and pseudomembrane, metal debris if metal-on-metal, cement fragments and necrotic bone β to bleeding bone, then copious pulsatile lavage (3 to 6 litres). Residual debris continues the osteolysis that causes early failure.
- Map the defect against the anatomic landmarks: obturator foramen (inferior), teardrop (medial), ischium (posteroinferior), anterosuperior rim (superior).
- Measure superior migration, rim and column integrity, and medial-wall status; confirm the Paprosky classification (often worse than imaging suggested), which determines reconstruction.
- Loose cemented stem: apply traction with an extraction device and gentle twisting; it usually comes out leaving the cement mantle.
- Well-fixed cemented stem: do NOT force it (a femoral fracture is guaranteed). Remove cement with flexible osteotomes (proximal to distal, gentle tapping, perforation risk), a high-speed burr (work in quadrants, continuous irrigation to avoid heat necrosis, stay in cement not bone) or ultrasonic tools (safer but slower). A distal cement plug may need a 2 to 3cm cortical window for access.
- Well-fixed cementless stem: an extended trochanteric osteotomy (ETO) is mandatory β never force extraction or the femur will fracture.
- Curette all femoral osteolysis to bleeding bone; finalize the Paprosky femoral classification.
- Ream to bleeding subchondral bone; choose the construct by Paprosky type (full matrix in Background & Evidence): Type I or IIA a standard or jumbo cup (66 to 80mm); Type IIB/IIC porous-metal augments plus cup; Type IIIA a jumbo cup or cup-cage; Type IIIB a custom triflange or cup-cage plus allograft.
- Principles: 40 to 50 percent host-bone contact for biological fixation, under-ream 1 to 2mm for press-fit, multiple screws in the posterosuperior safe zone (avoid the anteroinferior quadrant over the iliac vessels, the medial wall, and the inferior quadrant over the obturator nerve), and restore the hip center with the cup in the Lewinnek safe zone (40 to 45 degrees inclination, 15 to 20 degrees anteversion).
- Match the stem to the Paprosky femoral type (full matrix in Background & Evidence): Type I a primary stem; Type II/IIIA an extensively coated stem (6 to 8 inch coating) for diaphyseal fixation with 2cm of distal scratch-fit, bypassing metaphyseal defects by 2 cortical diameters; Type IIIB a very long extensively coated stem or a modular tapered fluted stem (Wagner SL); Type IV a proximal femoral replacement (megaprosthesis) or an allograft-prosthesis composite.
- Use impaction grafting for contained defects and cortical strut grafts (2 to 3 onlay struts, 3 to 4 cerclage wires each) for cortical defects, perforations or ETO reinforcement.
- Test the construct comprehensively: posterior stability (90 degrees flexion, maximal adduction, maximal internal rotation β the most common dislocation direction); anterior stability (full extension, 40 degrees external rotation, slight adduction); superior escape (abduction plus external rotation if the cup is highly inclined); then full range of motion and impingement.
- Confirm soft-tissue tension is snug but not over-tight (excessive tension raises nerve-palsy risk; equal knee heights equal equal leg lengths), and check fluoroscopy: cup inclination 40 to 45 degrees, head centred, stem neutral, lesser trochanters symmetric.
- If unstable during trialing you MUST address it before final components β reposition the cup, change stem version, increase head size, increase offset, or use a constrained liner or dual-mobility cup. Do not proceed; an unstable trial guarantees post-operative failure.
- Acetabular: insert the final liner (verify fully seated); for dual mobility seat the inner bearing, for a constrained liner prepare the head locking mechanism.
- Femoral cementless: clean and dry the canal, impact the stem gently, confirm with fluoroscopy. Femoral cemented: cement restrictor distally, retrograde fill, pressurise, insert the stem and hold 8 to 10 minutes.
- Clean and dry the femoral taper and impact the head firmly (fully seated) to prevent fretting corrosion. Reduce the hip and re-test stability (should match the trials); final fluoroscopy to document positions and exclude fracture.
- If an ETO was performed, reduce the greater trochanter fragment anatomically and fix it with 2 to 3 cerclage wires or cables (proximal, mid, distal), optional lag screws if bone quality allows, and a strut graft if osteopenic; protected weight bearing for 6 to 12 weeks until union.
- Repair the abductors (gluteus medius/minimus to the greater trochanter with transosseous sutures or anchors; advancement or allograft if poor quality; counsel re Trendelenburg gait if completely deficient). Repair the capsule where tissue allows β it reduces posterior dislocation by 50 to 70 percent β though it is often too diseased in revision for loosening.
- Copious pulsatile lavage (3 to 6 litres), meticulous haemostasis, and a deep drain only if there is a large dead space.
- Layered closure: gluteus maximus fascia with a number-1 absorbable suture (strength layer), subcutaneous 2-0/3-0 absorbable to eliminate dead space, deep dermal 3-0/4-0 absorbable, and skin (staples, subcuticular absorbable, or interrupted).
- Sterile dressing (consider negative-pressure therapy for high-risk wounds). Place a 15 to 20 degree abduction pillow immediately β it prevents adduction (the most common dislocation position) and stays continuously for 6 weeks.
Excessive bone loss during cup removal is the most critical danger: it worsens the Paprosky classification and may make reconstruction impossible β stay on metal, never on bone. Watch for acetabular wall fracture (especially the posterior wall β may need plating or a cage), intrapelvic perforation through a deficient medial wall (vascular/visceral injury risk), sciatic nerve injury if the posterior column is breached, and incomplete debris removal (persistent osteolysis and early failure). Always look for an unrecognised pelvic discontinuity (motion between the superior and inferior hemipelvis) β it will fail without specific reconstruction (plating or a cage across the discontinuity).
A cup loosens and migrates early if host-bone contact is less than 40 percent. Instability follows if the center of rotation is not restored or the cup is malpositioned. Medial screws can penetrate intrapelvically injuring the iliac vessels or obturator nerve (the anteroinferior quadrant is the highest-risk and is avoided). An antiprotrusio cage fails catastrophically if its screw fixation is inadequate. Again, an unrecognised pelvic discontinuity defeats a standard cup.
Femoral perforation occurs in 1 to 5 percent of revisions during cement removal. Recognise it immediately. Manage a moderate mid-diaphyseal perforation with 1 to 2 cortical strut grafts spanning the hole by 2 cortical diameters (8 to 12cm) proximal and distal, secured with 3 to 4 cerclage wires/cables, and revise to a longer extensively coated stem that bypasses the perforation by 2 cortical diameters distally for stable fixation in intact bone. Protect it with touch-down or partial (20kg) weight bearing for 6 to 12 weeks until strut incorporation. An unrecognised perforation is a stress riser that propagates to fracture.
Never force the extraction of a well-fixed cementless or extensively coated stem β the femur will fracture. An extended trochanteric osteotomy (anterior one-third of the femur, 10 to 12cm, with the greater trochanter left attached to the vastus lateralis sleeve to preserve blood supply) gives wide, safe access to the canal and distal cement, and heals reliably after cerclage repair.
Aftercare & Complications
Weight bearing. Weight-bear-as-tolerated when the construct is well-fixed with no ETO, no strut graft and no fracture. Touch-down or partial weight bearing (about 20kg) for 6 to 12 weeks after an ETO, where strut grafts were used, where fixation is questionable, or after an intra-operative fracture. Non-weight-bearing is rare, reserved for an unstable construct. Progress from walker or crutches (6 to 12 weeks) to a single crutch, then cane, then independent. Hip precautions (posterior approach) β STRICT for 12 weeks (longer than the 6 weeks after a primary): no hip flexion greater than 90 degrees (elevated toilet seat, no bending forward), no adduction past midline (no crossing legs; abduction pillow in bed), no internal rotation (no pivoting on the operative leg), and sleep supine or on the operative side with a pillow between the legs. Post-operative management.
- Antibiotics: IV for 24 to 48 hours peri-operatively only (cefazolin 2g q8h, or vancomycin 15mg/kg q12h if MRSA risk); longer courses do not reduce infection.
- DVT prophylaxis is critical (revision is high-risk): LMWH (enoxaparin 40mg SC daily) or a DOAC (rivaroxaban 10mg PO daily, or apixaban 2.5mg PO BID) for 4 to 6 weeks minimum, plus mechanical prophylaxis and early mobilisation.
- Multimodal analgesia: scheduled paracetamol 1g q6h, an NSAID if not contraindicated (celecoxib 200mg PO BID), opioids sparingly, and regional anaesthesia where available.
- Transfusion: check haemoglobin 6 to 12 hours post-op; transfuse if Hb less than 70g/L, or less than 80g/L with symptoms (each unit raises Hb by about 10g/L).
- Monitoring: frequent neurovascular checks (foot dorsiflexion/plantar flexion, sensation, pulses) with a documented baseline; any new deficit is investigated immediately.
- Imaging: AP pelvis and lateral hip within 24 to 48 hours to document component positions, exclude fracture and establish a baseline.
- Discharge (days 3 to 5): pain controlled on oral medication, medically stable, mobilising safely with an aid, and adequate social support or rehab transfer arranged. Follow-up. 2 weeks (wound, remove staples), 6 weeks (radiographs, advance weight bearing if protected), 3 months (discontinue precautions at 12 weeks), 6 months (baseline), then annually for life with serial films to watch for migration, radiolucent lines and osteolysis β early re-revision before extensive bone loss gives better outcomes (and roughly 20 percent of painful revisions harbour occult infection, so re-workup first).
- Recognition
- Progressive activity-related pain; migration greater than 2mm, progressive radiolucent lines greater than 2mm, subsidence on serial films; functional decline
- Prevention
- 40 to 50 percent host-bone contact, implant matched to bone loss, biological fixation, anatomic hip center, stable initial fixation, complete osteolysis curettage
- Management
- Serial films every 6 to 12 months; early re-revision before extensive bone loss; re-workup for infection (about 20 percent occult); re-classify (usually worse); consider tertiary referral for complex cases
- Recognition
- Constant rest pain, constitutional symptoms, wound drainage or dehiscence; ESR greater than 30, CRP greater than 10; positive aspirate (WBC greater than 3000, PMN greater than 80 percent, positive culture)
- Prevention
- Meticulous sterile technique, appropriate peri-operative antibiotics, minimise operative time, gentle tissue handling, tension-free closure, glucose control in diabetics
- Management
- Early (less than 3 months): irrigation and debridement with liner exchange if organism favourable and components well-fixed. Delayed/virulent: two-stage revision (explant, spacer, 6 weeks IV antibiotics, reimplantation). Chronic/recurrent in a poor host: suppression or permanent spacer
- Recognition
- Sudden pain, deformity, inability to move the hip; posterior (flexed/adducted/internally rotated) or anterior (extended/externally rotated); confirm on film
- Prevention
- Comprehensive intra-operative stability testing, restore center and offset, Lewinnek safe zone, larger head (36 to 40mm), repair capsule and abductors, dual mobility in high-risk, strict 12-week precautions
- Management
- First: closed reduction under sedation, assess stability under anaesthesia, post-reduction films and CT (positions, impingement). Recurrent: full workup, re-revision for malposition or abductor deficiency, dual mobility or constrained liner
- Recognition
- Foot drop, numbness in the sciatic distribution; may present immediately or within 48 hours; document extent (complete vs partial, peroneal vs tibial)
- Prevention
- Early nerve identification and protection, avoid excess traction, limit lengthening to less than 2cm, gentle handling, care with the burr near the posterior cortex, protected retractors
- Management
- Immediate recognition and documentation, exam and EMG at 3 weeks; AFO for foot drop, physiotherapy; explore if complete palsy with no recovery by 6 months. About 40 to 60 percent recover partially or completely; 10 to 20 percent permanent
- Recognition
- Audible crack, sudden instability, visible fracture line; confirm with fluoroscopy; classify by Vancouver (AG, AL, B1, B2, B3, C)
- Prevention
- Avoid forceful insertion/extraction, ETO for well-fixed cementless stems, careful sequential reaming, prophylactic cerclage for thin cortices, strut grafts for defects
- Management
- AG/AL stable: observe. B1 (well-fixed stem): cerclage/cables plus strut graft. B2/B3 (loose stem): revise to a longer stem bypassing the fracture by 2 cortical diameters plus cerclage and struts. C (below stem): plate fixation or revise to a longer stem
- Recognition
- DVT: calf swelling and tenderness, asymmetric circumference, ultrasound. PE: dyspnoea, chest pain, tachycardia, hypoxia; CT pulmonary angiogram
- Prevention
- Mandatory LMWH or DOAC for 4 to 6 weeks, early mobilisation, mechanical prophylaxis, hydration, avoid prolonged bed rest
- Management
- Therapeutic anticoagulation (LMWH, DOAC or warfarin) for 3 to 6 months; IVC filter if anticoagulation is contraindicated or recurrent. PE: anticoagulation, oxygen, ICU if massive, thrombolysis or embolectomy if unstable
- Recognition
- Sudden pain after a fall or minor trauma, inability to bear weight; assess component stability (loose vs well-fixed); Vancouver classification guides treatment
- Prevention
- Osteoporosis screening and treatment, fall prevention, avoid stress-shielding from very stiff long stems, activity counselling, surveillance for osteolysis
- Management
- AG/AL stable: protected weight bearing. B1: ORIF plating bypassing the stem. B2: revise to a longer stem plus ORIF. B3: revise to a long stem plus strut grafts and allograft. C: ORIF plating
Viva & Exam Focus
PAPROSKYPAPROSKY β acetabular bone-loss assessment
Why it matters. Paprosky classification is essential for revision planning: the type determines the reconstruction, and preoperative classification ensures the correct implants and instruments are on the table.
ETO SAFEETO SAFE β extended trochanteric osteotomy principles
Why it matters. The ETO is the standard technique for removing a well-fixed cementless or extensively coated stem and for distal cement access, while preserving the abductor-trochanter blood supply for reliable union. Non-union runs 5 to 10 percent with inadequate fixation or early weight bearing.
- Location
- Exits the pelvis inferior to piriformis, courses about 2cm posterior to the hip capsule, descends the posterior thigh
- Protection
- Identify early through scar, vessel-loop isolation, protected retractors, stay anterior if not found, avoid traction β limit lengthening to less than 2cm
- Location
- Exits ABOVE piriformis, runs along the undersurface of gluteus medius, enters the muscle 3 to 5cm above the greater trochanter tip
- Protection
- Limit proximal dissection to less than 5cm above the trochanter, stay below the medius belly, avoid superior retractors beyond the safe zone
- Location
- Femoral triangle about 2 to 3cm anterior to the anterior capsule; lateral to medial: Nerve-Artery-Vein (NAV)
- Protection
- Careful identification and retraction in an anterior approach, avoid medial cup screws in the anteroinferior quadrant, fluoroscopy for screw depth
- Location
- On the inner pelvic wall, vulnerable to medial cup-screw penetration
- Protection
- Avoid the anteroinferior quadrant (highest vessel risk), avoid medial-wall perforation during reaming, fluoroscopy/navigation to verify screw length; posterosuperior quadrant is safest
- Location
- Run along the obturator foramen inferiorly at the level of the ischium
- Protection
- Avoid inferior cup screws directed toward the foramen, careful inferior reaming near the teardrop, direct ischial screws posteriorly not inferiorly
Clinical Decision Scenarios
Practise clinical reasoning and management decisions out loud
βA 68-year-old woman presents with progressive groin and thigh pain 12 years after a primary total hip replacement. X-rays show acetabular component migration 4mm superiorly with a 3mm radiolucent line at the bone-implant interface, and femoral stem subsidence of 8mm. ESR is 25mm/hr and CRP is 8mg/L. How do you proceed?β
βYou are performing revision THR for aseptic loosening. After removing a well-fixed cemented femoral stem using a high-speed burr and flexible osteotomes, you create a 2cm perforation in the lateral femoral cortex at the mid-diaphyseal level during cement removal. How do you manage this intraoperatively?β
βDescribe your systematic approach to acetabular reconstruction in a patient with Paprosky Type IIIB acetabular bone loss (severe rim loss, ischium and teardrop gone, 6cm superior migration, Kohler line discontinuous). What are your reconstruction options and how do you choose between them?β
Indications
- Aseptic loosening: progressive pain (thigh equals femoral, groin equals acetabular), migration greater than 2mm, progressive radiolucent lines greater than 2mm, osteolysis
- Failed non-operative management (activity modification, NSAIDs, walking aids)
- MANDATORY pre-revision infection workup with the 2018 ICM/MSIS score (97.7 percent sensitivity / 99.5 percent specificity)
- Goals: pain relief, functional improvement, stable construct, restore anatomy
Key anatomy
- Sciatic nerve: about 2cm posterior to the capsule, palsy risk 2 to 5 percent in revision β identify early, vessel loop, avoid traction, limit lengthening to less than 2cm
- Superior gluteal neurovascular bundle: enters gluteus medius 3 to 5cm above the greater trochanter β limit proximal dissection to less than 5cm
- Femoral neurovascular bundle: about 2 to 3cm anterior to the capsule; lateral to medial Nerve-Artery-Vein
- Acetabular landmarks: obturator foramen (inferior), teardrop (medial), ischium (posteroinferior), Kohler line (medial-wall integrity)
- Screw safe zone: posterosuperior quadrant; AVOID anteroinferior (iliac vessels), medial (intrapelvic), inferior (obturator nerve/vessels)
Critical steps
- Pre-op: aspiration (cell count, differential, 14-day culture), alpha-defensin; Paprosky classification (acetabular I to IIIB, femoral I to IV)
- Exposure: previous incision (excise scar, 18 to 25cm), identify the sciatic nerve early, extensive scar release
- Component removal: acetabular (stay on metal, preserve bone); femoral (ETO for well-fixed cementless; burr/osteotomes/ultrasonic for cement)
- Osteolysis curettage: remove ALL debris to bleeding bone; copious lavage 3 to 6 litres
- Reconstruction: 40 to 50 percent host-bone contact, Lewinnek safe zone (40 to 45 degrees inclination, 15 to 20 degrees anteversion); femoral 2cm distal scratch-fit
- Trial reduction: comprehensive stability testing and fluoroscopy; MUST be stable before final components
- ETO repair if performed: 2 to 3 cerclage wires, strut graft if osteopenic, protected weight bearing 6 to 12 weeks
Danger zones
- Sciatic nerve: scar encasement, traction (limit lengthening to less than 2cm), thermal injury from the burr β palsy 2 to 5 percent
- Superior gluteal nerve: dissection greater than 5cm above the trochanter causes permanent abductor paralysis
- Acetabular wall fracture: especially the posterior wall with bone loss during cup removal β may need plating or a cage
- Femoral perforation: 1 to 5 percent during cement removal β strut graft plus cerclage wires
- Intrapelvic penetration: medial cup screws in the anteroinferior quadrant (iliac vessels), medial-wall reaming if deficient
Technique pearls
- Paprosky acetabular: I/IIA standard or jumbo cup; IIB/IIC augments plus cup; IIIA jumbo or cup-cage; IIIB custom triflange or cup-cage plus allograft
- Paprosky femoral: I primary stem; II/IIIA extensively coated (2cm distal scratch-fit); IIIB long extensively coated or modular tapered; IV megaprosthesis or APC
- ETO: well-fixed cementless or extensively coated stem, or distal cement access; anterior one-third, 10 to 12cm, trochanter on the vastus lateralis
- Strut grafts for cortical defects, perforations, prophylaxis, ETO reinforcement β 2 to 3 onlay struts, 3 to 4 cerclage wires each
- Cup-cage for IIIA/IIIB: cage screwed to ilium/ischium for structure, cup cemented in for articulation; the cage has NO biological fixation
Complications
- Aseptic loosening 10 to 15 percent at 10 years (versus 95 to 98 percent primary survival)
- Infection 2 to 5 percent (higher than primary 0.5 to 1 percent); early (less than 3 months) irrigation/debridement plus liner exchange, delayed/virulent two-stage
- Dislocation 10 to 15 percent (versus 2 to 5 percent primary); posterior most common; dual mobility for high-risk
- Sciatic nerve palsy 2 to 5 percent; 40 to 60 percent recover, 10 to 20 percent permanent
- Intra-operative fracture 2 to 5 percent; late periprosthetic fracture 5 to 10 percent lifetime β Vancouver classification guides treatment
- Re-revision 10 to 15 percent at 10 years, 20 to 25 percent at 15 years; second-revision survival about 70 to 80 percent at 10 years
Post-op protocol
- Weight bearing: WBAT if stable; touch-down/partial 6 to 12 weeks if ETO, strut grafts or questionable fixation
- Hip precautions STRICT 12 weeks: no flexion greater than 90 degrees, no adduction, no internal rotation; abduction pillow continuously 6 weeks
- DVT prophylaxis critical: LMWH (enoxaparin 40mg SC daily) or DOAC (rivaroxaban 10mg PO daily) for 4 to 6 weeks minimum
- Antibiotics: IV 24 to 48 hours only (cefazolin 2g q8h or vancomycin 15mg/kg q12h)
- Follow-up: 2 weeks (wound), 6 weeks (films, advance weight bearing), 3 months (stop precautions at 12 weeks), 6 months, then annually for life
Exam tips
- ALWAYS start with 'I must rule out infection FIRST β aspiration is gold standard; ESR/CRP alone have a 30 percent false-negative rate'
- State the Paprosky classification explicitly (acetabular and femoral) β this shows a systematic approach
- Acetabular IIIB: 'Best is a custom triflange if time permits (3 to 6 month lead time), otherwise a cup-cage plus augments plus allograft'
- Femoral II/IIIA: 'Extensively coated stem for diaphyseal fixation β 2cm distal scratch-fit, bypass metaphyseal defects by 2 cortical diameters'
- Stability: 'Dislocation rate 10 to 15 percent β I test posterior, anterior, ROM and impingement; if unstable during trials I MUST address it before final components'
- Outcomes: '10-year survival 80 to 90 percent versus 95 to 98 percent primary; revision is salvage β pain relief and function, not high-impact activity'
- Always cite '40 to 50 percent host-bone contact' for biological fixation and the 'Lewinnek safe zone' for cup positioning
Background & Evidence
Epidemiology. Aseptic loosening and polyethylene-wear osteolysis are among the leading indications for revision hip arthroplasty worldwide. Convergent registry data (AOANJRR Australia; NJR England, Wales, Northern Ireland and Isle of Man; the Swedish and Norwegian arthroplasty registers; AJRR USA) consistently show that second-revision survivorship is lower than first-revision survivorship, that dislocation and re-revision rates after revision THR exceed those of primary THR, and that aseptic loosening and osteolysis remain leading revision indications globally. Over time the indications have shifted: aseptic loosening has declined as implants have improved, while wear and osteolysis are now prominent and infection accounts for roughly 15 to 20 percent of revisions. Pathoanatomy. Aseptic loosening begins at the bone-implant interface with particulate debris β overwhelmingly polyethylene, plus metal and cement fragments β phagocytosed by macrophages that release cytokines driving an osteolytic cascade. The resulting granulation membrane and bone resorption produce a fibrous interface instead of stable fixation, allowing component migration, progressive radiolucent lines and osteolytic cysts. The pain pattern follows the component (groin for acetabular, thigh for femoral), and progressive bone loss compounds the problem at each subsequent revision. Paprosky classification β the planning backbone. The Paprosky acetabular and femoral classifications remain the gold standard for describing bone loss and matching it to a reconstruction strategy. They are graded so that preoperative classification ensures the correct implants and instruments are on the shelf at surgery.
- Defining features
- Intact rim, intact columns, less than 2mm superior migration
- Reconstruction
- Standard uncemented hemispherical cup
- Defining features
- Intact rim, intact columns, 2 to 3cm superior migration
- Reconstruction
- Jumbo cup (66 to 80mm) or elevated hip center
- Defining features
- Superior/posterior rim deficiency, greater than 3cm migration
- Reconstruction
- Porous-metal augments plus cup
- Defining features
- Medial-wall osteolysis, intact rim
- Reconstruction
- Bone graft plus cup
- Defining features
- Rim loss but ischium and teardrop intact (less than 3cm migration)
- Reconstruction
- Jumbo cup OR cup-cage
- Defining features
- Severe rim loss, ischium and teardrop gone, Kohler line discontinuous (greater than 3cm migration)
- Reconstruction
- Custom triflange OR cup-cage plus allograft
- Defining features
- Minimal metaphyseal damage, intact diaphysis, good bone stock
- Reconstruction
- Standard primary stem (cemented or cementless)
- Defining features
- Damaged metaphysis, intact diaphysis greater than 4cm
- Reconstruction
- Extensively coated stem (6 to 8 inch coating)
- Defining features
- Severe metaphyseal damage, intact diaphysis greater than 4cm, expanded canal
- Reconstruction
- Extensively coated long stem OR modular tapered fluted stem (Wagner SL)
- Defining features
- Metaphyseal and proximal diaphyseal damage, less than 4cm intact diaphysis
- Reconstruction
- Very long extensively coated stem OR long modular tapered stem
- Defining features
- Extensive damage, no diaphyseal fixation possible
- Reconstruction
- Proximal femoral replacement (megaprosthesis) OR allograft-prosthesis composite
Key evidence. Paprosky's 1994 acetabular paper established the classification and showed that of 147 revised cups only 6 (4 percent) were unstable β all Type 3B β confirming that massive rim/column loss carries the highest failure risk and needs structural support. Della Valle and Paprosky (2004) extended the framework to the femur: the key question is how much intact diaphysis remains distal to the bone loss, dictating whether diaphyseal fixation is achievable. Parvizi and colleagues (2018) gave the field the validated 2018 ICM/MSIS scoring for periprosthetic infection (97.7 percent sensitivity / 99.5 percent specificity), anchoring the infection gate that must precede any "aseptic" revision. Younger and colleagues (1995) described the extended trochanteric osteotomy β the controlled anterior osteotomy that preserves the abductor-trochanter blood supply and enables safe removal of well-fixed stems. Sporer and Paprosky (2006) showed that trabecular-metal cups, with or without augments, achieve reliable fixation across a pelvic discontinuity by spanning it.
References
Acetabular defect classification and surgical reconstruction in revision arthroplasty: a 6-year follow-up
- 147 cemented cups revised to cementless hemispheric press-fit components, mean follow-up 5.7 years
- Established the Paprosky acetabular classification (Types 1 to 3B) graded by superior rim deficiency, columns, medial wall and host-bone availability
- Only 6 of 147 cups (4.0 percent) were radiographically/clinically unstable β ALL were Type 3B
- Adequate remaining host bone is required for ingrowth; structural allograft size, orientation and fixation determine survival
The femur in revision total hip arthroplasty: evaluation and classification
- Defines the Paprosky femoral classification (Types I to IV) by metaphyseal damage and length of intact supportive diaphysis
- Type I/II preserve diaphyseal scratch-fit; Type IIIA/IIIB have progressively less intact isthmus; Type IV has no usable diaphysis
- Reconstruction is matched to type: primary or extensively coated stems for I to IIIA, modular tapered fluted or long stems for IIIB, megaprosthesis or allograft-prosthesis composite for IV
- Preoperative classification ensures the correct implants and instruments are available at surgery
The 2018 Definition of Periprosthetic Hip and Knee Infection: an evidence-based and validated criteria
- Multi-institutional development (684 PJI, 820 aseptic) with external validation (222 PJI, 200 aseptic)
- Weighted score: serum CRP over 1mg/dL (2), D-dimer over 860ng/mL (2), ESR over 30mm/hr (1); synovial WBC over 3000/Β΅L (3), alpha-defensin (3), leukocyte esterase positive (3), PMN over 80 percent (2), synovial CRP over 6.9mg/L (1)
- Two positive cultures or a sinus tract are major criteria diagnostic of PJI; aggregate score of 6 or more equals infected
- Sensitivity 97.7 percent / specificity 99.5 percent, outperforming MSIS 2011 (79.3 percent) and the prior ICM definition (86.9 percent)
Extended proximal femoral osteotomy: a new technique for femoral revision arthroplasty
- Anterolateral one-third of the proximal femur osteotomised and levered open on an anterolateral periosteal/muscle hinge
- Creates an intact muscle-osseous sleeve (gluteus medius, greater trochanter, anterolateral diaphysis, vastus lateralis) preserving blood supply
- Gives wide exposure of the implant fixation surface and distal cement, avoids varus stem malposition and protects the trochanter
- First 20 patients: excellent cement/component removal with reliable healing after cerclage repair
Acetabular revision using a trabecular metal component for severe bone loss with pelvic discontinuity
- 13 hips with Paprosky Type IIIB defects and pelvic discontinuity reconstructed with a trabecular metal cup with or without an augment
- Fixation obtained both proximal and distal to the discontinuity (distraction technique)
- At mean 2.6 years, 12 of 13 hips were radiographically stable; only 1 showed possible loosening and none required reoperation
- Merle d'Aubigne score improved from 6.1 to 10.3
Further reading 1. Chen AF, Hozack WJ. Component optimization in revision total hip arthroplasty. Orthop Clin North Am. 2014;45(2):161-167. Comprehensive review of implant selection for revision hip arthroplasty based on bone loss β extensively coated stems, modular tapered stems, trabecular-metal cups, augments, and cages. 2. Younger AS, Duncan CP, Masri BA. Surgical exposures in revision total hip arthroplasty. J Am Acad Orthop Surg. 1997;5(1):55-64. Detailed surgical approach options for revision hip surgery β extended posterolateral approach, trochanteric slide, extended trochanteric osteotomy, and management of prior surgical approaches. 3. National joint replacement registries (AOANJRR Australia; NJR England, Wales, NI and IoM; Swedish Arthroplasty Register; Norwegian Arthroplasty Register; AJRR USA). Annual Reports, latest editions. Convergent registry data show second-revision survivorship is consistently lower than first revision, dislocation and re-revision rates after revision THR exceed those of primary THR, and aseptic loosening and osteolysis remain leading indications for revision worldwide β used here as global evidence rather than a single-country frame. 4. Lachiewicz PF, Soileau ES. Changing indications for revision total hip arthroplasty. J Surg Orthop Adv. 2005;14(2):82-84. Evolution of revision hip indications over time β aseptic loosening declining due to improved implants, polyethylene wear and osteolysis now leading indications, infection remaining 15 to 20 percent of revisions. 5. Masri BA, Meek RM, Duncan CP. Periprosthetic fractures evaluation and treatment. Clin Orthop Relat Res. 2004;(420):80-95. Comprehensive review of periprosthetic femoral fractures in revision hip surgery β Vancouver classification system, treatment algorithms based on fracture location and component stability, role of strut grafts and cerclage wires.
