Foot & Ankle

Scarf Osteotomy for Moderate-Severe Hallux Valgus

Surgical technique guide for Scarf Osteotomy for Moderate-Severe Hallux Valgus - FRCS exam preparation

Core Procedure
advanced
By OrthoVellum Medical Education Team

Reviewed by OrthoVellum Editorial Team

Editorial maintenance, source checking, and correction workflow • Published by OrthoVellum Medical Education Team

High Yield Overview

SCARF OSTEOTOMY FOR MODERATE-SEVERE HALLUX VALGUS

Medial longitudinal approach to 1st metatarsal, extending from mid-proximal phalanx to mid-metatarsal shaft | advanced

Critical Danger Structures

Danger 1: Dorsomedial Cutaneous Nerve

Location: Crosses incision line 2-3mm dorsal to typical approach

Protection: Identify and retract during superficial dissection, stay on capsule

Danger 2: Medial Plantar Digital Nerve

Location: 8-10mm plantar to MTP joint line

Protection: Limit plantar dissection during eminence removal, stay on bone

Danger 3: Plantar Medial Neurovascular Bundle

Location: 12-15mm plantar to metatarsal shaft

Protection: Maintain periosteal sleeve, avoid excessive plantar dissection

Danger 4: Medial Plantar Sesamoid

Location: 4-5mm plantar to articular surface

Protection: Visualize during eminence resection, avoid over-resection

Danger 5: Lateral Digital Neurovascular Bundle

Location: 5mm lateral to lateral capsule

Protection: Gentle lateral release staying on capsule, avoid blind dissection

Mnemonic

Z-PLANESCARF Osteotomy Geometry

Mnemonic

PARALLELPreventing Troughing Malunion

Indications

Primary Indications

  • Moderate-to-severe hallux valgus: HVA 30-40°, IMA 13-18°
  • Symptomatic bunion deformity with pain, difficulty with shoe wear
  • Failed conservative management: appropriate shoes, orthotics, NSAIDs
  • Adequate bone stock for osteotomy and fixation
  • Motivated patient understanding rehabilitation requirements

Special Considerations

  • DMAA abnormality: Can be addressed with rotational component
  • Metatarsus primus varus: IMA correction primary goal
  • Short first metatarsal: Scarf allows lengthening if needed
  • High DASA: Consider adjunct Akin osteotomy

Contraindications

Absolute

  • Active infection in surgical field
  • Inadequate vascularity to forefoot
  • Severe osteoarthritis MTP joint (consider arthrodesis)
  • Non-ambulatory patient

Relative

  • Mild deformity (HVA <30°, IMA <13°) - consider chevron
  • Very severe deformity (IMA >20°) - consider proximal/MTP fusion
  • Significant medical comorbidities
  • Inflammatory arthropathy (higher recurrence risk)
  • Poor bone quality (osteoporosis)
  • Smoker (impaired healing)
  • Unrealistic patient expectations

Pre-operative Assessment

Clinical Evaluation

  • Severity: Measure HVA and IMA on weight-bearing AP radiographs
  • DMAA assessment: Lateral deviation of articular surface
  • Sesamoid position: Tibial sesamoid subluxation grade (0-3)
  • Joint congruency: Congruent vs incongruent joint
  • MTP ROM: Check for arthritis (limited ROM contraindication)
  • Foot alignment: Assess pes planus, metatarsus adductus
  • Lesser toe deformities: May need concurrent correction
  • Neurovascular status: Pulses, sensation, capillary refill

Radiographic Planning

  • Weight-bearing AP and lateral foot radiographs
  • Sesamoid axial view if available
  • Measure: HVA (normally <15°), IMA (normally <9°), DMAA (normally <10°)
  • Assess: Sesamoid position, MTP joint congruency, arthritis
  • Plan correction: Estimate translation needed (roughly 1mm lateral translation corrects 2° of IMA)

Patient Counseling

  • Expected outcomes: 85-90% satisfaction, significant pain relief
  • Recovery timeline: 6 weeks protected weight-bearing, 3-4 months return to activity
  • Complications: Recurrence 5-10%, transfer metatarsalgia 10-15%, nerve injury 5-10%
  • Hardware: Usually retained unless prominent
  • Footwear: May need wider toe box permanently

Exam Viva Scenarios

Practice these scenarios to excel in your viva examination

VIVA SCENARIOStandard

EXAMINER

"What is troughing and how do you prevent it during scarf osteotomy?"

EXCEPTIONAL ANSWER
Troughing is dorsiflexion malunion where the capital fragment sinks dorsally into the metatarsal shaft creating a 'trough' deformity. It's the most common technical complication of scarf osteotomy occurring in 5-10% of cases. It causes transfer metatarsalgia to the lesser rays and is visible on radiographs as dorsal angulation at the osteotomy site. Prevention requires four key technical points: First, the horizontal cut must be PARALLEL to the plantar cortex throughout its length - I continuously palpate the plantar cortex with my finger during cutting to ensure this. Second, maintain a 2:1 dorsal to plantar ratio which keeps the cut in the dorsal two-thirds of the shaft. Third, avoid any dorsal angulation during the cutting - the blade must stay level. Fourth, position the capital fragment with slight plantarflexion and ensure good bony contact with impaction. If the horizontal cut is not parallel, the capital fragment will tend to dorsally angulate causing troughing.
VIVA SCENARIOStandard

EXAMINER

"Compare scarf and chevron osteotomies - when would you choose each and what are the key differences?"

EXCEPTIONAL ANSWER
Both are distal metatarsal osteotomies for hallux valgus but have distinct indications and characteristics. CHEVRON is my choice for mild to moderate deformity with HVA up to 30° and IMA up to 13°. It's a V-shaped osteotomy that's technically simpler with inherent stability from the geometry allowing single screw fixation. It has lower AVN risk around 0.5% and is quicker to perform. However, it allows limited translation - maximum 50% of shaft width - and is essentially a one-plane correction. SCARF is indicated for moderate to severe deformity with HVA 30-40° and IMA 13-18°. The key advantages are: it allows greater translation up to 70% of shaft width, provides true multi-planar correction - I can translate laterally, rotate to correct DMAA, shorten if needed, and plantarflex to prevent transfer metatarsalgia. The Z-shaped geometry provides excellent stability despite being a longer osteotomy. The disadvantages are: technically more demanding requiring full shaft exposure, requires two screws for fixation, slightly higher AVN risk at 1-2%, longer operative time, and the unique risk of troughing malunion from technical error. For severe deformity beyond scarf's range - IMA greater than 20° - I'd consider proximal osteotomy or MTP fusion.
VIVA SCENARIOStandard

EXAMINER

"After completing a scarf osteotomy with good bony correction, you check fluoroscopy and note the sesamoids are not reduced. What do you do and why is this important?"

EXCEPTIONAL ANSWER
Unreduced sesamoids after bony correction is a critical finding that must be addressed - it's associated with recurrence rates up to 50% if left uncorrected. Sesamoid reduction under the metatarsal head is one of my key endpoints for successful hallux valgus surgery. If the sesamoids remain subluxated despite adequate lateral translation of the metatarsal, this indicates the lateral soft tissue contractures are severe enough to require release. I would perform a lateral soft tissue release. My approach is typically through a separate small dorsal incision in the first web space between the first and second metatarsals. I release the lateral capsule of the MTP joint and detach the adductor hallucis tendon from its insertion on the lateral base of the proximal phalanx and lateral sesamoid. The critical danger here is the lateral digital neurovascular bundle which runs approximately 5mm lateral to the lateral capsule - injury causes permanent numbness of the lateral hallux and potential chronic pain. I stay directly on the capsular layer and use gentle spreading dissection. After release, I recheck the sesamoid position both clinically and fluoroscopically. The sesamoids should sit reduced under the metatarsal head. If still unreduced after adequate release, I would reassess my bony correction - I may need more lateral translation or there may be malrotation preventing sesamoid reduction.

Scarf Osteotomy - Exam Day Summary

High-Yield Exam Summary

References

  1. Barouk LS. Scarf osteotomy for hallux valgus correction. Local anatomy, surgical technique, and combination with other forefoot procedures. Foot Ankle Clin. 2000;5(3):525-558. PMID: 11232396.

  2. Crevoisier X, Mouhsine E, Ortolano V, Udin B, Dutoit M. The scarf osteotomy for the treatment of hallux valgus deformity: a review of 84 cases. Foot Ankle Int. 2001;22(12):970-976. PMID: 11783924.

  3. Jones S, Al Hussainy HA, Ali F, Betts RP, Flowers MJ. Scarf osteotomy for hallux valgus. A prospective clinical and pedobarographic study. J Bone Joint Surg Br. 2004;86(6):830-836. PMID: 15330023.

  4. Coetzee JC. Scarf osteotomy for hallux valgus repair: the dark side. Foot Ankle Int. 2003;24(1):29-33. PMID: 12540078.

  5. Kristen KH, Berger C, Stelzig S, Thalhammer G, Posch M, Engel A. The SCARF osteotomy for the correction of hallux valgus deformities. Foot Ankle Int. 2002;23(3):221-229. PMID: 11934064.

  6. Aminian A, Kelikian A, Moen T. Scarf osteotomy for hallux valgus deformity: an intermediate followup of clinical and radiographic outcomes. Foot Ankle Int. 2006;27(11):883-886. PMID: 17144947.

  7. Deenik A, van Mameren H, de Visser E, et al. Equivalent correction in scarf and chevron osteotomy in moderate and severe hallux valgus: a randomized controlled trial. Foot Ankle Int. 2008;29(12):1209-1215. PMID: 19138484.

  8. Bock P, Kluger R, Kristen KH, et al. The Scarf osteotomy with minimally invasive lateral release for treatment of hallux valgus deformity: intermediate and long-term results. J Bone Joint Surg Am. 2015;97(15):1238-1245. PMID: 26246258.

  9. Adam SP, Choung SC, Gu Y, O'Malley MJ. Outcomes after scarf osteotomy for treatment of adult hallux valgus deformity. Clin Orthop Relat Res. 2011;469(3):854-859. PMID: 20700675.

  10. Chong A, Nazarian N, Chandrananth J, Tacey M, Shepherd D, Tran P. Surgery for the correction of hallux valgus: minimum five-year results with a validated patient-reported outcome tool and regression analysis. Bone Joint J. 2015;97-B(2):208-214. PMID: 25628283.
