Foot & Ankle

Weil Osteotomy for Lesser Metatarsalgia and Metatarsal Length Abnormalities

Oblique metatarsal neck osteotomy parallel to weight-bearing surface for transfer metatarsalgia, plantar plate insufficiency, and metatarsal length discrepancy

Core Procedure
intermediate
By OrthoVellum Medical Education Team

Reviewed by OrthoVellum Editorial Team

Editorial maintenance, source checking, and correction workflow • Published by OrthoVellum Medical Education Team

High Yield Overview

WEIL OSTEOTOMY FOR LESSER METATARSALGIA AND METATARSAL LENGTH ABNORMALITIES

Dorsal approach to lesser metatarsal head | Oblique osteotomy parallel to weight-bearing surface | intermediate

Critical Danger Structures

Danger 1: Dorsal Digital Nerves

Location: 3-5mm from midline on medial and lateral borders of adjacent toes

Protection: Careful identification during superficial dissection, loupe magnification, gentle retraction with vessel loops if needed

Injury: 3-5% incidence - causes permanent numbness medial/lateral toe borders, neuroma formation

Danger 2: Plantar Neurovascular Bundles

Location: 8-10mm plantar to metatarsal head on medial and lateral sides, travel between metatarsal heads

Protection: Limit plantar dissection, avoid plantar cortex perforation with saw, control plantar penetration depth

Injury: Digital nerve numbness, arterial injury with vascular compromise, hematoma formation

Danger 3: Plantar Plate

Location: Plantar aspect of MTP joint - thick fibrocartilaginous structure connecting proximal phalanx to metatarsal head

Protection: Gentle plantar dissection if intact pre-operatively (often already torn), avoid excessive traction on toe

Injury: Iatrogenic tear if intact increases MTP instability, prolongs recovery

Danger 4: Metatarsal Head Blood Supply

Location: Retrograde intramedullary from diaphyseal nutrient artery, dorsal and plantar metaphyseal vessels

Protection: Preserve soft tissue attachments to capital fragment, avoid excessive periosteal stripping, copious irrigation

Injury: Avascular necrosis of metatarsal head (rare, less than 1% with good technique)

Danger 5: MTP Joint Articular Cartilage

Location: Dorsal articular margin of metatarsal head - critical landmark for osteotomy start point

Protection: Start osteotomy 2-3mm DISTAL to articular cartilage margin, careful marking before cutting

Injury: Intra-articular osteotomy causes chondral damage, accelerated arthritis, persistent pain

Mnemonic

PARALLELPARALLEL - Weil Osteotomy Key Technical Points

Mnemonic

FLOATINGFLOATING - Preventing Floating Toe After Weil Osteotomy

Primary Indications

Transfer Metatarsalgia

  • Most common indication - pain under 2nd MT head (80% of cases), 3rd MT 15%, 4th MT 5%
  • Results from first ray insufficiency (hallux valgus/rigidus, failed bunion surgery, short 1st MT)
  • Clinical: plantar callus under affected MT head, tenderness, positive drawer test
  • Radiographic: long metatarsal relative to adjacent MTs, disrupted metatarsal parabola
  • CRITICAL: Must assess and address first ray pathology - Weil alone will fail if 1st MT insufficient

Metatarsal Length Discrepancy

  • Long metatarsal causing disproportionate loading and pain
  • Iatrogenic (after adjacent MT shortening/amputation) or congenital
  • Goal: restore Maestro metatarsal parabola (2nd longest, 3 greater than 4 greater than 5, each 2-3mm shorter)
  • Weil allows precise controlled shortening 2-6mm

Plantar Plate Insufficiency with MTP Instability

  • Plantar plate tear/attenuation causing MTP joint instability, subluxation, or dislocation
  • Drawer test positive (greater than 2mm dorsal translation of proximal phalanx)
  • Crossover toe deformity (toe deviates over adjacent toe)
  • Weil decompresses MTP joint, reduces tension on plantar structures, allows healing without repair (80-90% success)

Freiberg Disease Stage II-III

  • Osteochondritis of lesser metatarsal head (2nd MT 68%, 3rd MT 27%)
  • Stage II: subchondral fracture, flattening
  • Stage III: central depression, loose bodies
  • Weil decompresses joint, removes damaged dorsal fragment, preserves plantar articular surface

Combination Pathology

  • Often multiple factors: long MT + plantar plate tear + MTP subluxation
  • Weil addresses all components through decompression and shortening

Contraindications

Absolute

  • Active infection (osteomyelitis, septic arthritis)
  • Severe peripheral vascular disease (non-healing wound risk)
  • Inadequate soft tissue coverage
  • Severe medical comorbidities precluding surgery

Relative

  • Poor bone quality (severe osteoporosis) - nonunion/hardware failure risk
  • Isolated lesser metatarsalgia without first ray assessment - WILL FAIL
  • Rigid claw/hammer toe requiring PIPJ surgery (Weil alone insufficient)
  • Active Charcot neuroarthropathy
  • Unrealistic patient expectations
  • Severe rheumatoid arthritis with multiple joint involvement
  • Prior failed Weil with same pathology

Preoperative Assessment

Clinical Examination

  1. Inspection

    • Plantar callus location - directly under MT head indicates overload
    • Crossover deformity - 2nd toe crossing over hallux medially
    • Toe alignment - varus/valgus, rotation
    • Hallux valgus severity, hallux rigidus
    • Swelling, erythema at MTP joint
  2. Palpation

    • Tenderness localized to plantar MT head
    • MTP joint synovitis
    • Plantar plate integrity
  3. Special Tests

    • Drawer test: Stabilize MT head, pull toe dorsally - greater than 2mm translation or pain suggests plantar plate tear
    • Lachman test: Dorsal subluxation of toe with longitudinal traction
    • Vertical stress test: Passive dorsiflexion of MTP - pain suggests plantar plate pathology
    • First ray mobility - dorsiflexion stiffness suggests hallux rigidus
    • Gastrocnemius tightness - Silfverskiöld test
  4. Neurovascular

    • Pulses (dorsalis pedis, posterior tibial)
    • Sensation - rule out neuropathy
    • Capillary refill

Radiographic Assessment

  1. Weight-bearing AP Foot

    • Metatarsal lengths - Maestro concept assessment
    • 2nd MT should be longest or equal to 1st
    • Progressive shortening 3 greater than 4 greater than 5 (2-3mm each)
    • MTP subluxation/dislocation
    • Freiberg disease changes
    • Hallux valgus angle, 1st MT position
  2. Weight-bearing Lateral Foot

    • First ray dorsiflexion
    • Metatarsal declination angles
    • Pes planus versus cavus alignment
  3. Oblique Foot

    • MTP joint arthritis
    • Sesamoid position

Quantifying Shortening Needed

  • Radiographic method: Measure MT protrusion distance relative to 2nd MT
  • Typical shortening 2-4mm restores normal parabola
  • Maximum 6mm - beyond this, floating toe risk significantly increases
  • Consider staged procedures if greater than 6mm needed

First Ray Assessment - CRITICAL

Why it matters: Transfer metatarsalgia occurs FROM first ray insufficiency

  • Short first MT: Measure relative to 2nd MT - if 2nd MT greater than 4mm longer, high suspicion
  • Dorsiflexed first MT: Lateral X-ray - first MT elevated relative to lesser MTs
  • Hallux rigidus: Limited dorsiflexion, osteophytes, joint space narrowing
  • Failed bunion surgery: History of excessive 1st MT shortening
  • If first ray insufficient: Must address (1st MT lengthening, plantar flexion osteotomy, MTP cheilectomy) BEFORE or concurrent with Weil

Weil Osteotomy - FRACS Exam Quick Reference

High-Yield Exam Summary

References

  1. Trnka HJ, Muhlbauer M, Zettl R, et al. Comparison of the results of the Weil and Helal osteotomies for the treatment of metatarsalgia secondary to metatarsophalangeal instability. J Bone Joint Surg Am. 1999;81(12):1760-1768.

    • Classic comparison study showing Weil superior outcomes with 85% good/excellent results versus 70% for Helal osteotomy. Established Weil as preferred technique for lesser metatarsalgia with MTP instability.
  2. Vandeputte G, Dereymaeker G, Steenwerckx A, et al. The Weil osteotomy of the lesser metatarsals: a clinical and pedobarographic follow-up study. Foot Ankle Int. 2000;21(5):370-374.

    • Pedobarographic analysis demonstrating significant reduction in plantar pressures under operated metatarsal heads (average 35% reduction). Confirmed biomechanical rationale for procedure.
  3. Migues A, Slullitel G, Bilbao F, et al. Floating-toe deformity as a complication of the Weil osteotomy. Foot Ankle Int. 2004;25(9):609-613.

    • Identified floating toe incidence of 15% in 72 osteotomies. Key risk factors: excessive shortening greater than 6mm, dorsiflexion malunion, immobilization. Recommended limiting shortening and early mobilization.
  4. Hofstaetter SG, Hofstaetter JG, Petroutsas JA, et al. The Weil osteotomy: a seven-year follow-up. J Bone Joint Surg Br. 2005;87(11):1507-1511.

    • Long-term outcomes study: 74% patient satisfaction at 7 years. Complications: stiffness 30%, floating toe 12%, transfer metatarsalgia 8%. Emphasized importance of early range of motion protocols.
  5. Beech I, Rees S, Tagoe M. A retrospective review of the Weil metatarsal osteotomy for lesser metatarsal deformities: an intermediate follow-up analysis. J Foot Ankle Surg. 2005;44(5):358-364.

    • Review of 52 procedures with average 2.8-year follow-up. AOFAS scores improved from 52 to 84 (p less than 0.001). Recurrence rate 12% correlated with failure to address first ray pathology.
  6. Highlander P, VonHerbulis E, Gonzalez A, et al. Complications of the Weil osteotomy. Foot Ankle Spec. 2011;4(3):165-170.

    • Systematic review of complications: stiffness 20-30% (most common), floating toe 10-15%, transfer metatarsalgia 5-10%, recurrence 10-15%. Provided comprehensive prevention strategies for each complication.
  7. Pascual Huerta J, Arcas Lorente C, Garcia Carmona FJ. The Weil osteotomy: a comprehensive review. Rev Esp Cir Ortop Traumatol. 2012;56(5):415-421.

    • Comprehensive technical review covering indications, surgical technique, fixation options, and outcomes. Emphasized angle parallel to weight-bearing surface as key technical point. (Spanish literature, widely cited internationally)
  8. Nery C, Coughlin MJ, Baumfeld D, et al. Lesser metatarsophalangeal joint instability: prospective evaluation and repair of plantar plate and capsular insufficiency. Foot Ankle Int. 2012;33(4):301-311.

    • Evaluated plantar plate repair with Weil osteotomy: 91% good/excellent results. Found similar outcomes with and without plantar plate repair, suggesting Weil decompression alone sufficient in most cases (80-90%).
  9. Melamed EA, Schon LC, Myerson MS, et al. Two modifications of the Weil osteotomy: analysis on sawbone models. Foot Ankle Int. 2002;23(5):400-405.

    • Biomechanical study analyzing effect of osteotomy angle. Confirmed angle parallel to weight-bearing surface (20-30° to shaft) provides optimal load distribution and allows predictable shortening.
  10. Maestro M, Besse JL, Ragusa M, et al. Forefoot morphotype study and planning method for forefoot osteotomy. Foot Ankle Clin. 2003;8(4):695-710.

    • Introduced Maestro metatarsal parabola concept: 2nd MT longest, 3 greater than 4 greater than 5 progressively shorter 2-3mm each. Established radiographic planning principles for Weil osteotomy to restore normal forefoot mechanics.
